3450 Sabin Brown Road • Wickenburg, AZ 85390
(800) 992-3833 • mail@bnproducts.com
Operating Manual
BNT-25X • BNT-40X • BNT-58X
DIGITAL DISPLAY SERIES
This tool has
passed ISO9001
International Quality System Certification
The charger has passed ETL Certification
Please read this manual carefully before using these
machines to make sure you are familiar with all safety and
warning instructions.
Page | 1
Advertisement
Table of Contents
Related Manuals for BN Products DIGITAL DISPLAY Series
Summary of Contents for BN Products DIGITAL DISPLAY Series
- Page 1 3450 Sabin Brown Road • Wickenburg, AZ 85390 (800) 992-3833 • mail@bnproducts.com Operating Manual BNT-25X • BNT-40X • BNT-58X DIGITAL DISPLAY SERIES This tool has passed ISO9001 International Quality System Certification The charger has passed ETL Certification Please read this manual carefully before using these machines to make sure you are familiar with all safety and warning instructions.
- Page 2 BNT-Series Tiger Tier™ Callouts Battery Charger Please read this manual carefully before using these machines to make sure you are familiar with all safety and warning instructions. Page | 2...
-
Page 3: Safety First
Safety First • This machine is a high-performance battery-operated tool. Failure to follow the warnings and instructions may result in an electric shock, fire, or serious injuries. • Always operate the tool with personal protection equipment (including eye protec- tion, etc.). Using the appropriate safety equipment at all times will avoid injury. •... -
Page 4: Safety Locks
Safety Locks Make sure that all safety features are operational before using any power tool. DO NOT OPERATE THE TOOL IF THE SAFETY LOCKS ARE NOT FUNCTIONAL. This tool is equipped with the following safety devices: The Main Switch: Please turn the main switch off when not in operation. •... -
Page 5: Battery And Charger Usage
BNT-40-Wire-P Diameter (in.) ø 0.03 (21 Gauge) Material Q195 Polycoated Length (in.) 3937 (approx) Battery and Charger Usage Before inserting or removing the battery from this tool, please set the main switch to the off position. • To avoid a short circuit to the battery, always use the battery terminal cover when it is not in use with the tool. - Page 6 • Turn on the main power switch and unlock the trigger. The tool is now ready for use. How to remove the wire coil spool Turn off the main power switch, lock the trigger • and remove the battery. Press the release lever and confirm that it is •...
-
Page 7: Replacement Of Gears
Replacement of Gears • Remove the screw that fastens the plastic cover over the motor. • Remove Wire Guide “C” which is fastened to the plate. • Remove the E-ring on Feed Gear B1. Press lever and remove feed gear. •... - Page 8 Page | 8...
- Page 9 Page | 9...
- Page 10 Page | 10...
- Page 11 • When not in use, store this tool carefully in the supplied case. It can be washed with a soft cloth and soapsuds after you finish work. Do not use petroleum chemicals or alcohol to clean this tool. • In the event that this tool malfunctions or drops in performance you can contact our Customer Service Repair Center: (800) 992-3833 or mail@bnproducts.com.
- Page 12 How To Clear A Wire Jam On The BNT X Series Rebar Tiers The three-beep audio error code on the BNT X Series Rebar Tier most likely signifies a wire jam in the nose of the tool. Here are the steps you can take to clear misfed wire. 1.
- Page 13 4. Reassemble the tool in reverse order. Make sure that the notch on the connecting plate fits into the half moon cutout on the wire guide as seen in Picture 5. **Note: A tiny bit of grease can be put on the linkage points and fixed cutter but not too much as this will attract debris.
- Page 14 For additional information including: • Product Parts List • Product Literature • BNT Wire Supplies • BNEX-40X - Arm extension with electronic trigger • BNH-40 Holster - Heavy-duty holster • BNTLI-20 - Replacement Lithium-ion Battery (18V) • BNTLI-20C - Replacement Charger for the BNTLI-20 Battery Visit www.bnproducts.com or call (800) 992-3833 NOTES: ____________________________________________________...
- Page 15 BNT Series Accessories & Supplies Page | 15...
- Page 16 3450 Sabin Brown Road • Wickenburg, AZ 85390 (800) 992-3833 • mail@bnproducts.com Page | 16...
