Operation (Reaction Tune)
4. Make sure the receiver is powered on before the Scout. Then turn the Scout on so that the initial-
ization command may be sent to the receiver.
5. Key up any radio and the Scout will automatically tune the receiver to the frequency of the radio.
AR8000
1. Upon powering the Scout on the LCD will display the words Scout followed by the current com-
munications language. Confirm that the Scout displays AR8000. If the current setting is not the
desired setting refer to the COMMUNICATIONS LANGUAGE section of this manual for infor-
mation on how to change to the desired setting.
2. Attach the flat flexible end of the SAC 8000 cable (optional) to the serial port underneath the bat-
tery compartment of the AR8000. Attach the 2.5mm portion of the cable to the CI-V jack located
on top of the Scout.
3. Make sure the AR8000 is powered on before the Scout. Then turn the Scout on so that the initial-
ization command may be sent to the AR8000.
4. Key up any radio and the Scout will automatically tune the AR8000 to the frequency of the
radio.
5. The Scout will also tune the AR8200 with an optional cable.
