Special Programming Table - Comelit Simplebus1 Ultra UT1010 Technical Manual

Special programming table

CODE DIP SWITCHES ON
195 1,2,7,8
196 3,7,8
197 1,3,7,8
198 2,3,7,8
199 1,2,3,7,8
206 2,3,4,7,8
207 1,2,3,4,7.8
211 1,2,5,7,8
215 1,2,3,5,7.8
216 4,5,7,8
217 1,4,5,7,8
218 2,4,5,7,8
219 1,2,4,5,7.8
220 3,4,5,7,8
221 1,3,4,5,7.8
222 2,3,4,5,7.8
202 2,4,7,8
203 1,2,4,7,8
210 2,5,7,8
214 2,3,5,7,8
229 1,3,6,7,8
230 2,3,6,7,8
231 1,2,3,6,7.8
223 1,2,3,4,5,7,8
224 6,7,8
225 1,6,7,8
241 1,5,6,7,8
242 2,5,6,7,8
184 4,5,6,8
185 1,4,5,6,8
186 2,4,5,6,8
245 1,3,5,6,7.8
246 2,3,5,6,7.8
247 1,2,3,5,6,7,8
248 4,5,6,7,8
252 3,4,5,6,7.8
253 1,3,4,5,6,7,8
232 4,6,7,8
233 1,4,6,7,8
234 2,4,6,7,8
235 1,2,4,6,7.8
236 3,4,6,7,8
145 1,5,8
146 2,5,8
FUNCTIONS
Audio-visual messages
Hebrew
Polish
Catalan
Galician
Basque
Danish
Norwegian
Swedish
Italian
French
Spanish
Dutch
Greek
English
German
Portuguese
Enables voice message (door opened warning) when the RTE contact is closed
Disables voice message (door opened warning) when the RTE contact is closed (default setting)
Enables visual messages and disables voice messages (default)
OFF: disables voice and visual messages
Actuator command management
N.B. Art. 1256 in generic actuator mode must not be present in the system.
C.NC.NO relay activation on actuator command: 2 sec (default)
C.NC.NO relay activation on actuator command: 4 sec
C.NC.NO relay activation on actuator command: 8 sec
Door lock
Door lock command on SE in AC (default)
Door lock command on SE in enhanced AC
Door lock command on SE in DC
Management of internal units connected to Art. UT1020: up to 70 (default)
Management of internal units connected to Art. UT1020: from 71 to 100
Door lock time: 100 msec
Door lock time: 200 msec
Door lock time: 500 msec
Door lock time: 2 sec + disabling tone (default)
Door lock time: 4 sec
Door lock time: 8 sec
Door lock confirmation tone: enabled
Lock-release always enabled (default)
Lock-release only enabled for user called
System functions
Awaiting response time: 60 sec (default)
Awaiting response time: 120 sec
Awaiting response time: 30 sec
Talk time: 90 sec (default)
Talk time: 180 sec
RTE input set as local lock-release input (default)
RTE input set as door open indication
