NuTone GSHH3K Specification Sheet

GShh3K
FRESh AiR SYSTEM
Whole-house hEPA Filtration + Fresh Air + heat Recovery = Better iAQ
FEATuRES
•
Fully integrated Whole-house High Efficiency Particle
Arrestment (HEPA) filtration with fresh air ventilation
and heat recovery - unit slows the moisture transfer
between the outdoor and indoor air, making it a great
solution for areas with high moisture content.
•
Allows homeowners to benefit from fresh air, cleaned
with the best available HEPA filtration technology,
keeping the house free of dust and allergen material
(99.7% efficiency at particles as small as 0.3
microns).
•
Unit also removes stale air from the house with
an energy efficient heat recovery process. Stale
air is exhausted out and fresh air is drawn in
simultaneously without the risk of contamination.
•
Ideal for tightly built single-family houses, houses
that need fresh air ventilation, or houses that need
to remove stagnant air generated from materials or
pollutants, while also controlling pollen or dust from
the indoor air.
•
One simple-to-install and simple-to-use unit;
eliminates need for multiple, individual units. Easy to
install with a patented tandem "Y"-shaped transition
with only a single outdoor outlet.
•
Easy-to-use wall switches for unit control.
•
3 products for the price of 1: An affordable way
to have whole-house HEPA filtration, fresh air
ventilation, and heat recovery.
REFERENCE
Broan-NuTone LLC Hartford, Wisconsin
QTY. REMARKS
SPECiFiCATioN ShEET
GENERAL SPECiFiCATioNS
•
For houses up to 6,000 sq. ft.
•
165 to 270 cfm (0.4 in. w.g.)
•
Voltage: 120 VAC
•
Frequency: 60 Hz
•
Dimensions: 29.4" x 22.9" x 17.8"
•
Weight: 42 lbs
•
Shipping Weight: 57 lbs
•
Warranty: 2 years on parts
•
HVI Rated of air flow: 105 cfm
•
Power Consumed (max): 232 Watts
•
Low mode: --
•
High mode: --
•
Recirculation mode: --
•
Supply air duct connections: 5" or 6" diameter
•
Exhaust air duct connections: 8" diameter
•
Filter: HEPA
•
Cabinet: ABS and EPS
•
Mounting: Suspension by chains and springs
•
Wall control modes: Off, Normal, Boost, and
Recirculation
•
Power: 152 Watts
•
Current: 2.0 Amps
•
Continuous duty, permanently lubricated motors
•
36" power cord
www.broan.com 800-558-1711
Project
Location
Architect
Engineer
Contractor
Submitted by Date
