NuTone HRV90H Specification Sheet

hRV90h
FRESh AiR SYSTEM
FEATuRES
•
20% smaller than comparable units / Designed for
applications where space is critical, such as closet
and utility rooms in condominiums, apartments, and
pre-fabricated homes. Also has compact footprint
design for an easy fit in mechanical rooms, closets,
and other tight-fit applications. A versatile solution for
the most demanding applications.
•
State-of-the-art ventilation technology / Performance
sized for new ventilation standards and will not
over-dry the house. The most flexible Heat Recovery
Ventilator (HRV) on the market.
•
Bottom door opening / Design allows easy access
from any angle.
•
Side (HRV90HS) and top (HRV90HT) port
configuration / Versatile design allows for vertical or
horizontal configuration, facilitating installation and
maintenance (factory-configured).
•
Removable electric drawer / Easy maintenance of
major sub-components.
•
Interchangeable core / Allows unit to be changed from
HRV to ERV in the summer.
•
Convenient three-mode wall control (VT4W)
(Optional) (Min/Max Intermittent: 20-min. On / 40-min.
Off).
REFERENCE
Broan-NuTone LLC Hartford, Wisconsin
QTY. REMARKS
SPECiFiCATioN ShEET
GENERAL SPECiFiCATioNS
•
For houses up to 3,000 sq. ft.
•
45 to 96 cfm (0.4 in. w.g.)
•
Voltage: 120 VAC
•
Frequency: 60 Hz
•
Dimensions: 12.81" x 22.56" x 19.81"
•
Weight: 39 lbs
•
Shipping Weight: 42 lbs
•
Warranty: 2 years on parts - 10 years on core
•
HVI Rated of air flow: 106 cfm
•
Power Consumed (max): 150 Watts
•
Supply air duct connections: 5" diameter
•
Exhaust air duct connections: 5" diameter
•
Filter: 30 ppi washable reticulated foam
•
Cabinet: 20 ga. Pre-painted steel
•
Mounting: Suspension by chains and springs
•
Wall control modes: Low/High Speeds
•
Power: 150 Watts
•
Current: 1.3 Amps
•
Continuous duty, permanently lubricated motors
•
36" power cord
www.broan.com 800-558-1711
Project
Location
Architect
Engineer
Contractor
Submitted by
HRV90H
Date
80F HRV90H.indd
