NuTone GSEH3K Specification Sheet

GSEh3K
FRESh AiR SYSTEM
Whole-house hEPA Filtration + Fresh Air + Sensible and Latent Energy Recovery = Best iAQ
FEATuRES
•
Fully integrated Whole-house High Efficiency Particle
Arrestment (HEPA) filtration with fresh air ventilation
and energy recovery - unit slows the moisture transfer
between the outdoor and indoor air, making it a great
solution for areas with high moisture content.
•
Allows homeowners to benefit from fresh air, cleaned
with the best available HEPA filtration technology,
keeping the house free of dust and allergen material
(99.7% efficiency at particles as small as 0.3
microns).
•
Unit also removes stale air from the house with an
energy recovery process that addresses sensible
and latent heat. Stale air is exhausted out and fresh
air is drawn in simultaneously without the risk of
contamination.
•
Ideal for single-family houses in humid areas, or
houses that need to remove stagnant air generated
from off-gassing carpets, sealing agents, chemicals,
and daily activities, while also controlling pollen, dust
and other particles.
•
One simple-to-install and simple-to-use unit;
eliminates need for multiple, individual units. Easy to
install with a patented tandem "Y"-shaped transition
with only a single outdoor outlet. Installation kit
included; allows for horizontal or vertical installation.
•
Easy-to-use wall switches for unit control.
•
3 products for the price of 1: An affordable way
to have whole-house HEPA filtration, fresh air
ventilation, and energy recovery.
REFERENCE
Broan-NuTone LLC Hartford, Wisconsin
QTY. REMARKS
SPECiFiCATioN ShEET
GENERAL SPECiFiCATioNS
•
For houses up to 6,000 sq. ft.
•
165 to 270 cfm (0.4 in. w.g.)
•
Voltage: 120 VAC
•
Frequency: 60 Hz
•
Dimensions: 29.4" x 22.9" x 17.8"
•
Weight: 50 lbs
•
Shipping Weight: 62 lbs
•
Warranty: 2 years on parts - 5 years on core
•
HVI Rated of air flow: 105 cfm
•
Power Consumed (max): 232 Watts
•
Low mode: 170 Watts
•
High mode: 232 Watts
•
Recirculation mode: 165 Watts
•
Supply air duct connections: 5" or 6" diameter
•
Exhaust air duct connections: 8" diameter
•
Filter: HEPA
•
Cabinet: ABS and EPS
•
Mounting: Suspension by chains and springs
•
Wall control modes: Off, Normal, Boost, and
Recirculation
•
Power: 152 Watts
•
Current: 2.0 Amps
•
Continuous duty, permanently lubricated motors
•
36" power cord
www.broan.com 800-558-1711
