NuTone 113022 Specification Sheet

MODEL 11000
CONVERTIBLE CANOPY

RANGE HOOD

Greater height increases collection of cooking
contaminants while eliminating the need for above-
the-range cabinets.
FEATURES
•
Infinite speed control
•
Washable aluminum filter
•
Damper/duct connector included
•
Accommodates a bright 100W bulb or 150W flood lamp
•
Converts to duct-free with addition of Microtek
filter No. 97007696 (available separately)
•
Distinctive styling in Hammered White and Hammered
Black
•
Available in 30" width
SPECIFICATIONS
SONES
VOLTS AMPS RPM VER. HOR.
120 3.0 2850 6.0 6.5
HVI-2100 CERTIFIED RATINgS comply with new testing
technologies and procedures prescribed by the Home Ventilating
Institute, for off-the-shelf products, as they are available to
consumers. Product performance is rated at 0.1 in. static pressure,
based on tests conducted in a state-of-the-art test laboratory.
Sones are a measure of humanly-perceived loudness, based on
laboratory measurements.
*RHP INDEX (Range Hood Performance) is a scientific
measure of the effectiveness of a range hood in removing
grease, smoke, dirt and other solid pollutants from the
air. The RHP Index compares the performance of each
hood to others.
Broan-NuTone LLC
REFERENCE QTY.
® System II
CFM
DUCTFREE
VER. HOR. RHP INDEX* DUCT SIZE
190 200 9.80 3¼" x 10"
Hartford, Wisconsin
REMARKS
SPECIFICATION SHEET
TYPICAL SPECIFICATION
Range hood shall be Broan Model 11000.
Unit shall be convertible between ducted (using a washable
aluminum filter) and duct-free (using a Microtek
filter).
Unit shall have an infinite speed, solid state speed control.
Hood shall have separate light switch. Motor to be lifetime
lubricated. RPM not to exceed 2850.
Air delivery shall be no less than 190 CFM and sound level
no greater than 6.0 Sones (vertical discharge), 200 CFM and
6.5 Sones (horizontal discharge). All air and sound ratings
shall be certified by HVI. Unit shall be U.L. listed.
www.broan.com 800-558-1711
Project
Location
Architect
Engineer
Contractor
Submitted by
System II
®
Date
80D 99041073E
