ENGINE PARTS LIST

NO. PART# DESCRIPTION
1 CRANKCASE ASSEMBLY
1.1 400201 CRANKCASE
1.2 93509 CRANKCASE OIL SEAL
1.3 93520 CRANKCASE OIL SEAL
1.4 403901 GOVERNOR SHAFT
1.5 96804 GOVERNOR SHAFT OIL SEAL
1.6 383902 RETAINING CLIP
1.7 245106 OIL SENSOR ASSEMBLY
1.8 91329 BOLT M6*16
1.9 404301 GOVERNOR GEAR ASSEMBLY
1.10 93012 AXLE BEARING
2 ALTERNATOR ASSEMBLY
2.1 402002 CAMSHAFT ASSEMBLY
2.2 406101 VALVE LIFTER
2.3 401901 PUSH ROD
3 400301 CRANKSHAFT
4 CRANKCASE COVER ASSEMBLY
4.1 93509 CRANKCASE OIL SEAL
4.2 240904 CRANKCASE LOCATING PIN
4.3 96222 CRANKCASE GASKET
4.4 400101 CRANKCASE COVER
4.5 91347 BOLT M8*30 GB/T5787-1986
245601-
4.6 DIPSTICK
295
4.7 93012 AXLE BEARING
5 SPEED CONTROL BRACKET ASSEMBLY
5.1 91329 BOLT M6*16
5.2 404001 SPEED REGULATING ARM
5.3 91822 BOLT M6*21
5.4 90016 NUT M6
5.5 402701 THROTTLE LEVER
5.6 404201 SPRING C
5.7 404101 SPRING B
5.8 407701 SPEED CONTROL BRACKET
6 LOWER GUARD ASSEMBLY
6.1 407601 UNDER GUARD
6.2 91325 BOLT M6*12
7 SHROUD ASSEMBLY
7.1 407501 WIND-LEAD-COVER
7.2 91325 BOLT M6*12
8 97108 SPARK PLUG
9 CYLINDER HEAD COVER ASSEMBLY
9.1 91329 BOLT M6*16
9.2 96225 HEADCOVER GASKET
9.3 401102 CYLINDER HEAD INTERNAL COVER
CYLINDER HEAD INTERNAL COVER
9.4 96226
GASKET
EXPLODED VIEWS
NO. PART# DESCRIPTION
9.5 401101 CYLINDER HEAD COVER
9.6 92036 SCREW
9.7 95603 BREATHER TUBE
9.8 94435 BREATHER TUBE CLIP
10 CYLINDER HEAD ASSEMBLY
10.1 401002 CYLINDER HEAD
10.2 401701 INTAKE VALVE
10.3 405901 EXHAUST VALVE
10.4 406001 VALVE SPRING
10.5 402101 ROCKER ARM
10.6 91818 BOLT
10.7 402201 VALVE RETAINER ASSEMBLY
10.8 241806 VALVE SEAL
10.9 241817 VALVE SPRING RETAINER
10.10 329930 VALVE LOCK CLAMP
10.11 241804 TOP CAP
10.12 91022 DOUBLE END BOLT M6*95
10.13 91007 DOUBLE END BOLT M8*38
10.14 260901 CYLINDER HEAD LOCATING PIN
10.15 96223 CYLINDER HEAD GASKET
10.16 91452 BOLT M10
10.17 96235 GASKET
10.18 402301 CARBURETOR CONNECTION BLOCK
11 PISTON & PISTON RING ASSEMBLY
11.1 401201 PISTON
11.2 401601 PISTON RING ASSEMBLY
11.3 401501 CONNECTING ROD ASSEMBLY
11.4 405501 PISTON PIN
11.5 241301 PISTON PIN RING
12 CARBURETOR ASSEMBLY
12.1 94403 FUEL LINE CLAMP
402804-
12.2 CARBURETOR ASSEMBLY
295
12.3 95727L FUEL LINE
12.4 517917 LOW PRESSURE HOSE
12.5 599302 FUEL LINE CLAMP
13 AIR CLEANER ASSEMBLY
13.1 91329 BOLT M6
13.2 90016 NUT M6
13.3 402901 AIR CLEANER ASSEMBLY
14 IGNITOR ASSEMBLY
14.1 97552 IGNITER
14.2 91331 BOLT M6
15 FLYWHEEL ASSEMBLY
15.1 244508 STARTER PULLEY
15.2 240401 FLYWHEEL ASSEMBLY
15.3 404601 IMPELLER
