NuTone Performance CV450 Specifications

CENTRAL VACUUM
SYSTEMS
CV450 Power Unit
This popular power unit delivers excellent cleaning
performance from dual motors and a combined 2
horsepower rating. Easily handles homes up to 6,000
square feet. Has 6-gallon capacity with replaceable bag
filtration for easy, no-mess dirt removal. Secondary
filter provides added motor protection.
FEATURES:
• Two, 2-stage bypass motors
• Convenient utility inlet on power unit
• Two-stage filtration with convenient replaceable bag
• 6-gallon capacity
• UL Listed
• Two Year Warranty
CV450
1
⁄
2
SPECIFICATIONS:
Motors. . . . . . . . . . . . . . . . . . . . . . . . . . . .Two, 2-Stage Bypass
Horsepower . . . . . . . . . . . . . . . . . . . . . . .2
Amperes . . . . . . . . . . . . . . . . . . . . . . . . .12.6
CFM at 2" opening . . . . . . . . . . . . . . . . .96
Water Lift . . . . . . . . . . . . . . . . . . . . . . . . .155"
Air Watts . . . . . . . . . . . . . . . . . . . . . . . . . .584
Air Power at Tank . . . . . . . . . . . . . . . . . .424
Air Power (ASTM) . . . . . . . . . . . . . . . . .262
Switch & Inlet on Power Unit . . . . . . . . .Yes
Recommended Circuit . . . . . . . . . . . . . .20 amp Dedicated
Primary Filtration . . . . . . . . . . . . . . . . . . .Replaceable Bag
Capacity . . . . . . . . . . . . . . . . . . . . . . . . . .6 Gallon
Secondary Filtration . . . . . . . . . . . . . . . .Yes
UL Listed . . . . . . . . . . . . . . . . . . . . . . . . .Yes
Housing . . . . . . . . . . . . . . . . . . . . . . . . .White Steel
Tank Dimensions . . . . . . . . . . . . . . . . . .13
UPC ... . . . . . . . . . . . . . . . . . . . . . . . . . . .7 84891 77450 8
NuTone Central
Cleaning Systems –
an important part of
Total Indoor Air
Quality...solutions
for today's lifestyles!
1
⁄ Total
2
1
⁄ "Dia. x 36" H
4
