- Page 1 Operation instructions SR 530 Hood Revision: 03 OI06H-0421 SR 530 2020-10-05...
-
Page 2: General Information
The SR 530 together with the SR 500 Powered Air-Purifying Respirator system of components to provide respiratory protection against certain particulates, organic vapors, acid gases and other inorganic gases. Refer to the NIOSH Approval Label for a list of approved components and NIOSH cautions and limitations. - Page 3 Unpacking Check that the equipment is complete in accordance with the packing list and has not been damaged in transit. Packing list: • Hood with breathing hose. • User instructions • Cleaning tissue OI06H-0421 SR 530 2020-10-05...
- Page 4 1.1 Remove the protective 1.3 Connect the hose to the film from the visor. fan unit and turn it clockwise about 1/8 of a turn. 1.2 Check that the O-ring of the hose is in place. OI06H-0421 SR 530 2020-10-05...
- Page 5 6.2CFM (175 l/min). If minimum flow is not achieved, check that - the flow meter is held upright, - the ball moves freely, - the bag seals well around the hose. OI06H-0421 SR 530 2020-10-05...
- Page 6 Connect the hose, put the fan unit on and start it. See the user instructions for the SR 500. 3.2 Hold the hood upside down. Grip each side of the hood opening with one hand. OI06H-0421 SR 530 2020-10-05...
- Page 7 3.4 Adjust the neck size of 3.5 Make sure that the the hood by means of the breathing hose runs along elastic neck strap. your back and is not twisted. OI06H-0421 SR 530 2020-10-05...
- Page 8 Proceed as follows: Snap off the valve cover. 4.2 Slip off the membrane. 4.4 Press the valve cover into place. A clicking sound indicates that it is in place. OI06H-0421 SR 530 2020-10-05...
- Page 9 Proceed as follows: Pick away one end of the sweatband so that it is removed together with the tape. Pull sweatband off. 5.2 Remove the protective paper and fit the new sweatband. OI06H-0421 SR 530 2020-10-05...
- Page 10 MEK, acetone, or toluene as those may like. Rinse the equipment and damage or distort materials. leave it to dry. 6.1 Sundström cleaning tissues SR 5226 are recommended for daily care. OI06H-0421 SR 530 2020-10-05...
- Page 11 6.3 Snap off the valve cover 6.5 Clean the valve seat and from the valve seat. check that the valve seat is 6.4 Slip of the membrane. 6.6 Clean the valve cover on Clean the exhalation the inside and outside. membrane. OI06H-0421 SR 530 2020-10-05...
-
Page 12: Maintenance Schedule
The schedule represents the minimum requirements for maintenance routines in order to ensure that equipment will always be in functional condition. Before After Annually Visual inspection • • • Functional check • • Cleaning • • Change of exhalation • membrane OI06H-0421 SR 530 2020-10-05...
