SECO-LARM ENFORCER SD-962AR-36A Installation Manual

Rim Exit Device Installation Manual
Specifications:
SD-962AR-36A
For Doors 1-3/4" thick, wood or metal
Hand Non-Handed
Latchbolt Stainless-steel, 3/4" throw
Dead Latch Stainless-steel, 5/8"
Strike
For 5/8" stop, plus shim for 1/2" stop
Spring Stainless-steel
Chassis Steel
Cover High-density rust-resistant alloy
Rail Assembly Steel
End Cap Steel
Dogging Allen-type dogging standard
WARNING: Incorrect mounting which leads to exposure to rain or moisture inside the enclosure could damage the
device and void the warranty.
WARRANTY
This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for a period of one (1) year from the date of sale to the original consumer customer. SECO-LARM's obligation is
limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect,
repair, or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines
that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or repair only, at
SECO-LARM's option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential
personal or property damages of any kind to the purchaser or anyone else.
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the
SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right
to change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2007 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in
whole or in part, without the written permission of SECO-LARM.
SECO-LARM ® U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
Made in T aiwan
Website: www.seco-larm.com
®
PITSW6
E-mail: sales @ seco-larm.com
ExitDevicebIMPg1.cdr
SECO-LARM U.S.A., Inc.
Installation Manual
ENFORCER
SD-962AR-36A
Rim Exit Device
Features:
•
For exit doors --
Allows exit from inside while locked from outside.
•
Reversible non-handed design.
•
For metal or wood doors up to 1 3 / " thick.
4
•
Stainless steel 3/4" throw latch bolt.
•
Separate deadlocking latch --
Prevents the use of credit cards
or similar means to open the latch bolt.
What It Does:
SECO-LARM's SD-962AR-36A exit device, when mounted on the inside of a door to block entry to a protected premises,
securely locks the door from outside access while allowing users inside the protected premises to exit. The stainless-steel
enclosure protects the exit device from abuse, yet easily unlocks the door from the inside by users who require exit. It can
be connected to a door handle with a lock, or any physical locking device, on the outside of the door in order to allow
entry to personnel with keys to the protected premises.
Fig. 1 -- Dimensions:
1
19 / "
2
(495mm)
2 / 1 "
2
(64mm)
2"
(51mm)
5 / 3 "
4
(146mm)
®
•
Allen-type 1/4-turn dogging lock --
Allows the exit device to be unlocked
for extended periods of time.
•
Includes all needed hardware for typical installation.
•
Works with standard external door handle/lock devices
(not included).
•
Fits doors from 30" to 48" wide.
•
Heavy-duty steel construction.
•
Stainless steel spring.
2 / 1 "
2
Extended
(64mm)
3
1 / "
4
Depressed
(44mm)
32 3 / "
4
(832mm)
1 / 3 "
4
(44mm)
2"
(51mm)
