Grounding

Ensure the shield ground wire on the MMX1000 Series Modular MAXX box is
grounded to earth ground .
A. Mounting to Earth Ground
When mounting MMX1000 Series Modular MAXX boxes to earth ground (such as
an I-Beam), mount the shield ground wire using a mounting bolt through one of
the mounting brackets on the enclosure .
Figure 5. Proper Shield Grounding Technique
7
