IN-COMMAND NCSP35 Troubleshooting Manual
  1. Manuals
  2. Brands
  3. IN-COMMAND Manuals
  4. Control Systems
  5. NCSP35
  6. Troubleshooting manual

IN-COMMAND NCSP35 Troubleshooting Manual

Rv control and monitoring system
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
Troubleshooting Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the NCSP35 and is the answer not in the manual?

Questions and answers

Related Manuals for IN-COMMAND NCSP35

Summary of Contents for IN-COMMAND NCSP35

  • Page 1 Troubleshooting Guide...
  • Page 4 BCM Pin Values Name BCM Function Note A DMM Fresh 1Tank In Input from Sending Unit 0-.74V = EMPTY (○○○) Fresh 2 Tank In Input from Sending Unit .75-1.74V = 1/3 (●○○) Black 1 Tank In Input from Sending Unit 1.75-3.59V = 2/3 (●●○) Black 2 Tank In Input from Sending Unit...
  • Page 5 BCM Pin Values (Cont.) Name BCM Function Note Motor 5 Retract Out Output Reversing Polarity DC Motor 12V/GND Motor 5 Extend Out Output Reversing Polarity DC Motor 12V/GND Motor 4 Retract Out Output Reversing Polarity DC Motor 12V/GND Motor 4 Extend Out Output Reversing Polarity DC Motor 12V/GND...
  • Page 6 End User License Agreement (EULA) screen will appear. Upon NCSP3 Functionality Test accepting the EULA, the “Enter New Passcode” screen will appear. Enter your new passcode and confirm. The Body Control Module (BCM) should be wired correctly, without loose connections, and connected to 12 VDC at pin 42. A LED will indicate that the BCM is receiving 12 VDC.
  • Page 7 Use the “Set” temperature up and down arrows to set the desired HVAC Testing temperature. The “Set” temperature can be adjusted between 55 to 90F. When testing the HVAC (Climate Function), make sure each “Zone” is displaying a room (Zone) temperature. Use the “Mode” button to cycle through Fan, Cool, Heat and Auto modes.

  • Page 8: Troubleshooting

    (Both Systems)If no HVAC function, check to see if the room (zone)  Please review the NCSP35 User Manual for further HVAC operational temp is blank. If it is, make sure the RV-C cables are connected to instructions. You can scan the QR code shown below or use the...

  • Page 9: Water Tank

     If the Battery Disconnect switch is off, turn it on. (Some For additional troubleshooting, call ASA Electronics Technical Support at 1- models pull the slide power through the battery disconnect.) 877-845-8750, email info@asaelectronics.com or visit our iN-Command support page at https://in-command.net/...
