Em-Trak B924 CLASS B I Manual page 2

PHYSICAL SPECIFICATION
Size
Weight
ELECTRICAL SPECIFICATION
Power Supply
Power Consumption (WiFi & Bluetooth On)
WiFi & Bluetooth Off
Galvanic Isolation
CONNECTORS
VHF Antenna Output
VHF Radio Input
GNSS Antenna
NMEA2000
Power/NMEA0183
USB
DATA INTERFACES
Physical Data Interfaces
WiFi Type
Bluetooth Type
STANDARDS COMPLIANCE
AIS Standards
Product Safety Standards
Environmental Standard
Serial Data Interface Standards
GNSS Performance Standards
NMEA2000 Interface Standard
HEAD OFFICE
em-trak Marine Electronics Ltd
Wireless House
Westfield Industrial Estate
Midsomer Norton
Bath BA3 4BS
United Kingdom
150 X 110 mm
370g
12 - 24V DC
3.35W (280mA @ 12V)
2.95W (245mA @ 12V)
NMEA0183 Inputs Only
SO239
SO239
TNC
Standard 5 Way Micro
Connector
12 Way Circular Multipole
Micro B
NMEA0183 (2)
NMEA2000
USB
IEEE 802.11 (a/b/g)
BLE 4.0 Classic
IEC62287-1 Ed 3
ITU-R M.1371-5
EN60950-1 2006
+A11:2009 +A1:2010
+A12:2011 +A2:2013
EN62311:2008
CFR 47 PT1.1310 (2016)
Health Canada Safety
Code 6
ARPANSA Radiation
Protection Series No.3
IEC60945 Ed 4
IEC61162-1 Ed 5.0
IEC61162-2 Ed 1.0
IEC61108-1 Ed 2.0
IEC61108-02 Ed 1.0
NMEA2000 Ed 3.101
T +44 (0)1761 409 559
F +44 (0)1761 410 093
E enquiries@em-trak.com
W www.em-trak.com
EU
VHF TRANSCEIVER
Access Scheme
Operating Frequency Range
AIS Receiver Sensitivity
AIS Transmit Power
GNSS RECEIVER & ANTENNA
Channels
GNSS Type & Performance
Environmental Standard
Category
Waterproofing
Operating Temperature
ANTENNA SPLITTER
VHF Radio Transmit Path Loss
Receive Path Loss
Path Switching Time
VHF Radio Path Rating
Path On Power Failure
Antenna Fault Detection
Switch Type
IN THE BOX
1 X AIS TRANSCEIVER
1 X POWER AND DATA CABLE (2M)
1 x VHF RADIO ACCESSORY CABLE
1 X FLEXI-FIT MOUNTING BRACKET
COMPLETE WITH SCREWS & OPTIONAL FIXING TAPE
WARRANTY
With em-trak you can buy with confidence. If you are unhappy
with your new product for any reason, within two days of receipt
and subject to the product and packaging being complete and
undamaged, you may return it to us for a full refund. We are sorry,
but we cannot accept the return of any product if you have not
advised us in writing within 48 hours of receiving your em-trak
product, or if it has been used and or damaged or if any of the
package is incomplete. All em-trak products benefit from our
three year global warranty. In the unlikely event of a problem,
please contact our Customer Support department (24/7) at
support@em-trak.com and one of our experts will work with you
to resolve your issue or arrange the repair or replacement of your
em-trak product. The warranty is invalidated if the product has
been incorrectly used, damaged or tampered.
USA OFFICE
em-trak Marine Electronics Ltd
470 Atlantic Avenue
4th floor
Boston
02210
USA
CSTDMA
156MHz To 163MHz
-111dBm
2W (+33dBm)
72
GPS/Galileo + GLONASS
Or BEIDOU
Exposed
IPx6 & IPx7
-25ºc To +55ºc
< 1dB
0dB
< 10us
> 25W
VHF to Antenna
Yes
Solid-state
T +1 617 273 8395
F +1 617 273 8001
E enquiries@em-trak.com
W www.em-trak.com
