Seagull Models EXTRA EA300L EP Assembly Manual page 12

EXTRA EA300L EP
4mm.
Balsa.
3) Attach the motor to the front of the electric
motor box using four 3mm blind nut, four
M3x15mm hex head bolts to secure the motor.
Please see picture shown.
Electric motor.
12
4mm
4mm.
Epoxy.
M3 x 15mm.
Instruction Manual.
122mm.
4) Locate the plywood battery tray to the
fuselage.
1800mAh-2100mAh.
5) Attach the speed control to the side of the
motor box using two-sided tape and tie wraps.
Connect the appropriate leads from the speed
control to the motor. Make sure the leads will
not interfere with the operation of the motor.
Battery
Battery.
Epoxy.
Battery.
Speed control
Speed control.
