Code : SEA 362
ASSEMBLY MANUAL
Speciications:
Wingspan--------------- 85.0 in (215.9 cm).
Wing area--------------- 775.0 sq.ins (59.0 sq.dm).
Weight------------------- 16.8lbs (7.6 kg).
Length------------------- 59.2 in (150.3 cm).
Engine/Motor size----- 35-40cc gasoline.
Radio--------------------- 8 channels with 9 servos.
Motor 160/ 2700watt/ ESC 70A-100A/ Lipo 9s-10s.
Electric propeller 18x8-20x10.
1

Advertisement

Table of Contents
loading

Related Manuals for Seagull Models SEA 362

Summary of Contents for Seagull Models SEA 362

  • Page 1 Code : SEA 362 ASSEMBLY MANUAL Speciications: Wingspan--------------- 85.0 in (215.9 cm). Wing area--------------- 775.0 sq.ins (59.0 sq.dm). Weight------------------- 16.8lbs (7.6 kg). Length------------------- 59.2 in (150.3 cm). Engine/Motor size----- 35-40cc gasoline. Radio--------------------- 8 channels with 9 servos. Motor 160/ 2700watt/ ESC 70A-100A/ Lipo 9s-10s.

  • Page 2: Kit Contents

    Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc INTRODUCTION hank you for choosing the ARTF by SG MODELS CESSNA 208 GRAND CARAVAN . he 85’’ CESSNA GRAND CARAVAN was designed with the intermediate/advanced sport lyer in mind. It is a semi scale airplane which is easy to ly and quick to assem- ble.

  • Page 3: Additional Items Required

    KIT CONTENTS LED LIGHT SET SEA362 CESSNA 208 GRAND CARAVAN Please see pictures below. 85 INCH WINGSPAN 35-40 1. Fuselage 2. Wing set (3) 3. Tail set (2) 4. Canopy 5. Cowling 6. Wing tube 7. Cockpit and Pilot 8. Landing gear 9.
  • Page 4 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc silicone sealant. silicone sealant.
  • Page 5 Epoxy.
  • Page 6 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc C/A glue. C/A glue.
  • Page 7 INSTALL THE AILERONS CONTROL HORN Epoxy. Fiberglass control horn. Epoxy. Ailerons control horn. Epoxy.

  • Page 8: Installing The Aileron Servos

    Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc INSTALLING THE AILERON SERVOS Minimum servo spec. Torque : 115.3 oz-in (8.3 kg-cm) @ 4.8V; 157.8 oz-in (11.3 kg-cm) @ 6.0V 180.1 oz-in (12.9 kg) @ 7.4V Because the size of servos difer, you Set the aileron hatch in place and use a may need to adjust the size of the precut Phillips screw driver to install it with four...

  • Page 9: Aileron Pushrod Installation

    INSTALL FLAP CONTROL HORN Fiberglass control horn. AILERON PUSHROD INSTALLATION 65mm. Epoxy.
  • Page 10 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc Epoxy. 85mm. Epoxy. INSTALLING THE FLAP PUSHROD Please see below pictures.

  • Page 11: Landing Gear Installation

    LANDING GEAR INSTALLATION Locate items needed for landing gear installation.
  • Page 12 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc 4x25mm. 2x8mm.
  • Page 13 3x4mm.

  • Page 14: Nose Gear Installation

    Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc 3x4mm. NOSE GEAR INSTALLATION Locate the parts needed to attach the nose gear.
  • Page 15 3x4mm.
  • Page 16 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc M3x20mm. M3x15mm.
  • Page 17 3x20mm...
  • Page 18 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc INSTALLING THE RECEIVER SWITCH Install the switch into the precut hole in it the side, of the fuselage. 3/32” Hole. Trim and cut. Epoxy.

  • Page 19: Fuel Tank Installation

    Switch. Carefully bend the second nylon tube up at a 45º angle. his tube is the vent tube. INSTALLING THE ENGINE SWITCH Test it the stopper assembly into the tank. It may be necessary to remove some of the lashing around the tank opening using a modeling knife.

  • Page 20: Mounting The Engine

    Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc MOUNTING THE ENGINE Please see images below. Vent tube. Fuel pick up tube. Fuel ill tube. Balsa wood. Epoxy. Epoxy. Connect the lines from the tank to the engine and muler. he vent line will connect to the muler and the line from the clunk to the carburetor.
  • Page 21 M5x110mm. Pushrod wire. 180mm. Ignition Modude.
  • Page 22 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc Move the throttle stick to the closed po- sition and move the carburetor to closed. Use a 2.5mm hex wrench to tighten the screw that secures the throttle pushrod wire. Make sure to use threadlock on the screw so it does not vibrate loose.
  • Page 23 Tape the cowl to the fuselage using low-tack tape. M3x15mm. Because of the size of the cowl, it may be nec- essary to use a needle valve extension for the high speed needle valve. Make this out of suf- icient length 1.5mm wire and install it into Use a drill and drill bit to drill the holes the end of the needle valve.
  • Page 24 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc Attach the motor mount to the front of the electric motor box using four ELECTRIC POWER CONVERSION blind nut, four M5x25mm hex head bolts to secure the motor. Please refer to images below. Locate the items neccessary to install the electric power conversion included with your model.
  • Page 25 hen, use 7mm drill bit to enlarge the Attach the speed control to the side holes on the electric motor box. of the motor box using two-sided tape and tie wraps. Connect the appropriate leads from the speed control to the mo- tor.

  • Page 26: Installing The Spinner

    Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc HINGING THE ELEVATOR Battery. Glue the elevator hinges in place using tthe same techniques as shown in images below. INSTALLING THE SPINNER Install the spinner backplate, propeller and spinner cone. he propeller should not touch any part of the spinner cone.
  • Page 27 Epoxy. Epoxy. INSTALL ELEVATOR CONTROL HORN Epoxy. Fiberglass control horn.

  • Page 28: Hinging The Rudder

    Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc Elevator iberglass control horn. Epoxy. Epoxy. HINGING THE RUDDER Glue the top three rudder hinges in place using the same techniques used to hinge the elevator. he lower hinge will be glued when the in/rudder assembly is attached to the fu- selage.
  • Page 29 INSTALL RUDDER CONTROL HORN Repeat steps to install the rudder control horn as same as steps done for elevator. Epoxy. Fiberglass control horn. Epoxy. Rudder iberglass control horn.
  • Page 30 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc INSTALLING THE HORIZONTAL STABILIZER Using a ruler and a pen, locate the cen- terline of the horizontal stabilizer, at the trailing edge, and place a mark. Use a tri- angle and extend this mark, from back to front, across the top of the stabilizer.
  • Page 31 INSTALLING VERTICAL STABILIZER Epoxy. When you are sure that everything is aligned correctly, mix up a generous amount of 30 Minute Epoxy. Apply a thin Using a modeling knife, remove the layer to the top and bottom of the stabi- covering from over the precut hinge slot lizer mounting area and to the stabilizer cut into the lower rear portion of the fu-...
  • Page 32 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc Slide the vertical stabilizer into the slot in the top of the fuselage. he rear edge of the stabilizer should be lush with the rear edge of the fuselage and the lower rudder hinge should engage the precut hinge slot in the lower fuselage.
  • Page 33 hread one clevis and M2 lock nut on to each elevator control rod. hread the horns on until they are lush with the ends of the control rods. Elevator and rudder pushrod assembly shown in photos below. Locate items necessary to install rudder pushrod.
  • Page 34 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc RUDDER PUSHROD INSTALLATION Repeat steps as same as steps done for elevator. INSTALL THE WINDOW Parts requirement.See pictures below. 885mm.
  • Page 36 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc...
  • Page 37 Epoxy.
  • Page 38 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc 2x6mm.
  • Page 39 2x6mm. 2x6mm.
  • Page 40 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc INSTALLATION COCKPIT, PILOT AND CANOPY Locate items necessary to install. Epoxy.
  • Page 41 Epoxy.
  • Page 42 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc CARGO POD INSTALLATION Locate items necessary to install. INSTALLING TOW RELEASE FOR SAIL PLANE Screw the aero-tow mechanism into the hole just behind the canopy, and apply thread-lock luid to prevent the coupling and nut from working loose.
  • Page 43 INSTALLING BATTERY - RECEIVER Plug the servos leads and the switch lead into the receiver. Plug the battery pack lead into the switch also. Wrap the receiver and battery pack in the protective foam rubber to protect them from vibration. Receiver.
  • Page 44 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc hen, install struts on the wings and fuselage. Wing bolt.
  • Page 45 4x25mm.
  • Page 46 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc 3x10mm. M4x25mm. hread locker glue. 4x25mm.

  • Page 47: Antenna Installation

    ANTENNA INSTALLATION - Parts requirement.See pictures below. 2x8mm.
  • Page 48 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc INSTALLING THE PITOT TUBES & POD Parts needed are shown in images below:...
  • Page 49 ATTACHMENT WING- FUSELAGE Attach the aluminium tube into fuselage. Epoxy. M4x25mm.
  • Page 50 Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc BALANCING An important part of preparing the air- crat for light is properly balancing the M4x25mm. model. 1) Attach the wing panels to the fuselage. Make sure to connect the leads from the aileron to the appropriate leads from the receiver.

  • Page 51: Control Throws

    CONTROL THROWS Ailerons: Rudder: High Rate : High Rate : Up : 25 mm Right : 25 mm Down : 25 mm Let : 25 mm Low Rate : Low Rate : 80mm. Up : 20 mm Right : 20mm Down : 20 mm Let : 20 mm Elevator:...

  • Page 52: Flight Preparation

    Instruction Manual. Cessna 208 Grand Caravan 85 inch wingspan 35-40cc FLIGHT PREPARATION PREFLIGHT CHECK Check the operation and direction of the 1) Completely charge your transmit- elevator, rudder, ailerons and throttle. ter and receiver batteries before your irst day of lying. A) Plug in your radio system per the 2) Check every bolt and every glue joint manufacturer’s instructions and turn eve-...
  • Page 53 If you have any queries, or are interested in our products, please feel free to contact us Factory : 12/101A - Hamlet 4 - Le Van Khuong Street - Dong hanh Ward - Hoc Mon District - Ho Chi Minh City - Viet Nam. Oice : 62/8 Ngo Tat To Street - Ward 19 - Binh hanh District - Ho Chi Minh City - Viet Nam Phone : 848 - 86622289 or 848- 36018777...
