A 3217C
HDMI & Infra-Red Cat5e/6 Extender UTP Balun
Operating Instructions
This long distance HDMI balun converter allows a 1080p HDMI source to
be extended up to 50m away using economical Cat 5e or 6 UTP
cabling - without sacri cing signal quality! Infra-red control signals can
also be relayed both ways, allowing you to control your equipment
remotely. Extended Display Identi cation Data (EDID) can be read and
saved from the display. Ideal for situations where HDMI source devices
are located greater than 15m away from the screen. HDMI loop output
on transmitter for local viewing.
Advertisement
Related Manuals for Dynalink A 3217C
Summary of Contents for Dynalink A 3217C
- Page 1 A 3217C HDMI & Infra-Red Cat5e/6 Extender UTP Balun Operating Instructions This long distance HDMI balun converter allows a 1080p HDMI source to be extended up to 50m away using economical Cat 5e or 6 UTP cabling - without sacri cing signal quality! Infra-red control signals can also be relayed both ways, allowing you to control your equipment remotely.
- Page 2 Operating Instructions HDMI Extender over single Cat5e/6 cable With Loop HDMI Output Operating instruction HDMI Extender over single Cat5e/6 cable with Loop HDMI Output Dear Cust omer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product.
-
Page 3: Net Weight
Operating Instructions S p e c i f i c a t i o n s Operating Temperature Range -5 to +35℃(+23 to +95 ) ℉ Operating Humidity Range 5 to 90%RH (No Condensation) Data transfer speed 6.75Gbps HDMI Receptacle x 2 (1xHDMI input, 1xHDMI loop output) RJ45 Receptacle x 1 Connectors on Transmitter Power DC Receptacle x 1... - Page 4 Operating Instructions Panel Description Transmitter Panel HDMI Output 1 . HDMI Output. 2 . EDID copy button. 3 . Status of power input. When power input on, the LED lights. 4 . Status of signal connection. When this works well, the LED lights. 5 .
- Page 5 Operating Instructions Connection Diagram HDMI Cable Cat5e/6 Cable Transmitter HDMI In Loop HDMI Out HDMI Source HDMI Extender over single Cat5e/6 cable PS3,Blu-ray DVD player, etc. with Loop HDMI Output 3D TV Cat5e/6 x1 IR-TX TV remote Receiver HDMI Out 3D TV IR-TX DVD or STB remote...
- Page 6 Altronic Distributors warrants this product for one year from date of purchase from Altronics or its resellers to the consumer. If this item is part of an installation or another product, please contact the installer or supplier for your warranty. During the warranty period, we undertake to repair or replace your product at no charge if found to be defective due to a manufacturing fault.
