5. WIRING DIAGRAM

FUSE
AUDIO/POWER
HARNESS
(See Figure 1)
7 8 7
5 6 5
3 4 3
1 2 1
Figure 2
ISO CONNECTOR 4PIN+8PIN
FEMALE WITH MALE TERMINAL
ISO CONNECTOR WIRING CHART
PIN WIRE COLOR
A4 YELLOW
A5 BLUE
RED
A7
BLACK
A8
B1 VIOLET
VIOLET/BLACK
B2
GREY
B3
B4 GREY/BLACK
B5 WHITE
B6 WHITE/BLACK
B7 GREEN
B8 GREEN/BLACK
20-PIN
REAR LINE OUT
GREY
FRONT LINE OUT
BLACK
CONNECTOR
(See Figure 2)
8
6
4
2
FUNCTION/LABEL
BATTERY(+)
POWER ANTENNA
IGNITION(ACC)
GROUND
RIGHT REAR SPEAKER (+)
RIGHT REAR SPEAKER (-)
RIGHT FRONT SPEAKER (+)
RIGHT FRONT SPEAKER (-)
LEFT FRONT SPEAKER (+)
LEFT FRONT SPEAKER (-)
LEFT REAR SPEAKER (+)
LEFT REAR SPEAKER (-)
WHITE
AUX IN
RED
SUB WOOFER
BLUE
WHITE
WHITE
RED
WHITE
RED
ISO
WIRE COLOR
PIN
GREY/BLACK
1
GREY
2
VIOLET
3
VIOLET/BLACK
4
5
GREEN
6
GREEN/BLACK
7
RED
8
BLACK
9
RED
10
WHITE
11
WHITE/BLACK
12
13
BLUE
14
YELLOW
15
BLACK
16
WHITE
17
RED
18
BLACK
19
20 WHITE
E - 6
ANTENNA
JACK
YELLOW
RCA-TO-RCA CABLES
(not supplied)
RCA-TO-RCA CABLES
(not supplied)
AMP
FUNCTION/LABEL
RIGHT FRONT SPEAKER (-)
RIGHT FRONT SPEAKER (+)
RIGHT REAR SPEAKER (+)
RIGHT REAR SPEAKER (-)
LEFT REAR SPEAKER (+)
LEFT REAR SPEAKER (-)
IGNITION(ACC)
REAR PRE-AMP LINE OUT COMMON
RIGHT REAR PRE-AMP LINE OUT
LEFT FRONT SPEAKER (+)
LEFT FRONT SPEAKER (-)
POWER ANTENNA
BATTERY(+)
CHASSIS GROUND
LEFT FRONT PRE-AMP LINE OUT
RIGHT FRONT PRE-AMP LINE OUT
FRONT PRE-AMP LINE OUT COMMON
LEFT REAR PRE-AMP LINE OUT
ANTENNA
