Boss Audio Systems 3160 User Manual

Boss Audio Systems 3160 User Manual

Mp3-compatible in-dash cd receiver with rds function
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3160 and is the answer not in the manual?

Questions and answers

Related Manuals for Boss Audio Systems 3160

Summary of Contents for Boss Audio Systems 3160

  • Page 2 1. BUTTONS LOCATION AND FUNCTIONING 1. BUTTONS LOCATION AND FUNCTIONING PANEL VARIABLE COLOR DISPLAY RELEASE POWER BUTTON(COLOR) BUTTON BUTTON ENCODER AUDIO MUTE VOLUME BUTTON BUTTON BUTTON ID3 TAG INFORMATION BUTTON DISPLAY BUTTON BUTTON AUTOMATICALLY SOURCE STORE / PRESET BUTTON / BUTTON SCAN BUTTON SUB-WOOFER...

  • Page 3: Handling Compact Discs

    2. HANDLING COMPACT DISCS MOISTURE CONDENSATION On a rainy day or in a very damp area, moisture may condense on the lenses inside the unit. Should this occur, the unit will not operate properly. In such a case, remove the disc and wait for about an hour until the moisture has evaporated.

  • Page 4: Installation

    Before finally installing the unit, connect the wiring temporarily and make sure it is all connected properly and the unit and system work properly. Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions.

  • Page 5: Din Rear-Mount (Method B)

    Trim Plate Installation: Push the trim plate against the chassis until it is fitted. You must do this before you install the front panel, otherwise it can't be attached. DIN REAR-MOUNT (METHOD B) Installation using the screw holes on the sides of the unit. Fastening the unit to the factory radio mounting bracket.

  • Page 6: Detachable Control Panel (D.c.p .)

    Removing The Detachable Control Panel (D.C.P .). PANEL RELEASE BUTTON Attaching the DCP CAUTION DO NOT insert the D.C.P from the left side. Doing so may damage it. The D.C.P can easily be damaged by shocks. After removing it, place it in a protective case and be careful not to drop it or subject it to strong shocks.

  • Page 7: Wiring Diagram

    5. WIRING DIAGRAM FUSE 20-PIN AUDIO/POWER HARNESS (See Figure 1) Figure 2 ISO CONNECTOR 4PIN+8PIN FEMALE WITH MALE TERMINAL ISO CONNECTOR WIRING CHART WIRE COLOR FUNCTION/LABEL YELLOW BATTERY(+) BLUE POWER ANTENNA IGNITION(ACC) BLACK GROUND VIOLET RIGHT REAR SPEAKER (+) VIOLET/BLACK RIGHT REAR SPEAKER (-) GREY RIGHT FRONT SPEAKER (+)
  • Page 8 6.PANEL OPEN/CLOSE OPERATION After the CD is loaded or unloaded, push the panel at position A and the panel will return to its original position. in correct position E - 7...

  • Page 9: Basic Operations

    7. BASIC OPERATIONS 1) PANEL RELEASE BUTTON (REL) Press this button to remove the control panel. 12)POWER ON/OFF BUTTON Press this button to turn on or off the power. 6) DISPLAY BUTTON (DISP) Press this button to view Clock, Programme Type (PTY), and Frequency of the station in listening. 3) VARIABLE COLOR DISPLAY BUTTON (COLOR) This unit is equipped with variable color display: The display color can keep changing automatically.

  • Page 10: Audio Operations

    8. AUDIO OPERATIONS 10) ENCODER VOLUME BUTTON Turn this knob to adjust desired volume level. 5) AUDIO BUTTON Press this button to select desired audio function. ORDER OF FUNCTION: VOLUME(VOL) -> BASS(BAS) -> TREBLE(TRE) ->BALANCE(BAL) ->FADER(FAD) While the selected function is displayed, turn Volume Knob to adjust the level within 5 seconds, otherwise the unit will return to volume adjustment mode.

  • Page 11: Radio Operations

    9. RADIO OPERATIONS 11) AUTO MEMORY STORE/PRESET SCAN BUTTON (AS/PS) 1.PRESET SCAN: Press AS/PS button briefly to enter Preset Scan mode, it will scan all the preset stations in the memories, you can hear that it will stay on each station for about 5 seconds. 2.AUTO MEMORY STORE: Press AS/PS button for couple of seconds to enter Auto Store mode, this feature will automatically scan the current band and enter up to 6 strongest stations into the 6 preset memories.

  • Page 12: Pty Button

    Some broadcasting stations may change their program from normal broadcasting to regional broadcasting for a certain period. When regional mode is off, the region identification in the PI code is ignored; the radio may switch to a local variant of the current program. When region mode is on, the radio will only switch to a program carrying the exact same PI code.
  • Page 13 This code is used to designate the current program material being broadcast. With this feature, you can search the programs that match the selected program type, which is chosen from a specific list of types. - EON (Enhanced Other Networks Information) It is a supplementary service enabling the radio to obtain information not only from the current station but also from the others.
  • Page 14 10.CD OPERATIONS M1) PAUSE BUTTON (PAUSE) Press this button to pause CD play, press again to release pause. M2) SCAN BUTTON (SCAN) Press this button, the first 10 seconds of each track will be played sequentially until this button is pressed again, then normal play will resume at the current track. M3) REPEAT BUTTON (REPEAT) Press this button, the current track will be played repeatedly until this button is pressed again.
  • Page 15 11.MP3 OPERATIONS (ENCODER VERSION) Notes : - An MP3 directory is shown in this manual as “Directory”, and an MP3 file is shown as “Track”. - Maximum length of file name : 28 characters. - Maximum length of directory : 16 characters. - Maximum number of tracks per disc : 254.
  • Page 16 DIRECTORY (2) SEARCH / TRACK NAME BY USING ENCODER VOLUME KNOB Under MP3 Play Mode, press MP3 MENU BUTTON twice, the display shows “ * “. Rotate the ENCODER VOLUME KNOB for selecting the character. In this Encoder Search mode, SELECT button use as move cursor.

  • Page 17: Remote Control

    12.REMOTE CONTROL OPERATIONS: Radio Mode 1. Power Power On/Off 2. Volume Up/Down Adjust Vol,Bas, Tre,Fad,Bal 3. ID3/DISP Display Clock 4.TA TA Function 5. Tuning Up/Down Tuning/Seek Up/Down 6. AF AF Function 7. PTY PTY Function 8. Mute Mute Select Vol, Bas, 9.

  • Page 18: Specifications

    CD PLAYER System Usable disc Sampling frequency No of quantization bits Frequency Number of channels S/N Ratio Frequency Range Intermediate Frequency Usable Sensitivity Stereo Separation S/N Ratio GENERAL Power Supply Polarity Speaker impedance Power Output REMARK : Specifications subject to change without notice. Compact disc audio system Compact disc 44.1KHz...

  • Page 19: Troubleshooting

    Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom No power The car ignition is not on. The fuse is blown. Disc cannot be loaded Presence of CD disc inside or ejected the player.

This manual is also suitable for:

Rds3160mp3
