General instructions and precautions

Rx Tx
Tx
Rx
4.4

Alignment

≤ 5˚
Tx
< 1.5 m
Reflective surface
Tx
© CEDES | V 1.0
 Never scratch or paint the optical lenses because they form the
 Do not bend or twist the edges!
 Oil can damage the cables. Contamination must be avoided
 Although the GridScan/Mini-SR is insensitive to direct sunlight,
Tx Rx
 Avoid interference from blinking lights or infrared light sources
 Do not install the GridScan/Mini-SR in places where the emitter
 Make sure to place the connection plugs for both the emitter
Tx
Rx
The optical axis of the emitter (Tx) and the receiver edge (Rx)
need to be aligned towards each other to ensure the light curtain
functions reliably.
≤ 10˚
Rx
Reflective surfaces near to or parallel to the safeguarded area can
cause reflections. Although the GridScan/Mini-SR is very robust
against such reflections, it is always advisable to keep a reasonable
Rx
distance between the sensor edges and any reflective surface.
light path! Do not drill additional holes into the profile. Unpack
the profiles just before installation in order to avoid damage.
at all times!
avoid all unnecessary exposure if possible, most especially to
the receiver.
such as photo cells or other light curtains.
and receiver edges are directly exposed to light sources such as
FL tubes or energy saving lamps.
and receiver at the same end.
