Summary of Contents for Beam Man Down RST410
- Page 1 RST410 Man Down Pendant Kit Suitable for Beam Tracking Terminals & Other Comparable Devices. Beam Communications Pty Ltd...
-
Page 2: User Information
Information furnished by BEAM Communications Pty Ltd (BEAM) is believed to be accurate and reliable. However, no responsibility is assumed by BEAM for its use, or for any infringement of patents or other rights of third parties, which may result from its use. -
Page 3: Package Contents
Man Down Kit - F5 Installation & User Manual Package Contents Check that your Man Down Kit - F5 package contains: AA Batteries Man Down Pendant Gateway Interface Box Pendant Case Lanyard Windshield Gateway Quick Start Guide Q U IC K S T A R T G U ID E S ui ta bl... -
Page 4: Optional Accessories
Optional Accessories PotsDOCK 9555 IridiTRAK 430 LeoTRAK 470 LeoTRAK 480 Conventions in this Manual Warnings, cautions and notes appear throughout this manual and are represented by following conventions. WARNING / CAUTION: This symbol and associated text indicate a warning note providing information to prevent damage to equipment or personal injury. -
Page 5: Table Of Contents
Turning the pendant on or off Physical Specifications Man Down pendant mechanical drawings Windshield gateway mechanical drawings Specification and Aprovals Environmental specifications Technical support/Warranty Assuring quality of Iridium service Obstructions Cabling RF Interference Symptoms of RF interference Mitigation of RF interference Beam Warranty Conditions... -
Page 7: Beam Communications
Beam specializes in Voice, Data, Tracking and customized solutions. Beam develops innovative products and services to meet market demands and niche applications. Beam’s leading edge products are deployed in a wide range of vertical markets including Maritime, Transport, Government, Defence, Mining, Construction, Forestry, Emergency Services, Relief Aid, Telemetry and Rural Telephony. -
Page 8: About This Equipment
About this equipment Key Features Man Down Pendant Single large push button (16 mm, 5/8 in dia.) Integrated motion sensor triggers an alert message after 60 seconds of no motion. Vibration motor, two bi-color LEDs and a buzzer act as feedback mechanisms. -
Page 9: Installation Guidelines
Man Down Kit - F5 Installation & User Manual Installation Guidelines Device Connections PotsDOCK BEAM iridium Ringer Bluetooth Mute Track ALERT Wired Connection... -
Page 10: Rst430 Iriditrak Wiring Diagram
RST430 IridiTRAK Wiring Diagram Status (Config Port) Pin 1 (-) 0V Power Ground Pin 2 (+) Vin 9 to 32VDC Pin 3 (IN) On / Off Pin 4 (IN) Ignition Sense / Accessory Pin 5 (IN) Alarm Loop A Pin 6 (OUT) Alarm Loop A Pin 7 (IN) Alarm Loop B... - Page 11 Man Down Kit - F5 Installation & User Manual Pin 1 Power Supply: 20W min. 2A or 3A fuse is recommended. Pin 2 (0 to 32Vdc Tolerant) ON (1) > +7Vdc Pin 3 OFF (0) 0V < +1Vdc When On/Off not required, Wire-link pin 3 to 2 to keep On.
-
Page 12: Connecting To A Rst430 Iriditrak
Installation Guidelines Connecting to a RST430 IridiTRAK Gateway Interface Box Panic IN Not in use Panic Out Not in use Not in use Not in use # Sleep Power Connector RST430 Pin 1 Pin 2 IridiTRAK Pin 3 Pin 4 Pin 5 Pin 6 Pin 7... -
Page 13: Connecting To A Potsdock 9555
Man Down Kit - F5 Installation & User Manual Connecting to a PotsDOCK 9555 Man-down Pendant Gateway Interface Box Panic IN Not in use Panic Out Not in use Not in use Not in use # Sleep Power Connector 9555 PotsDOCK Alert Loop IN Alert Loop OUT... -
Page 14: Potsdock Wiring Diagram
PotsDOCK 9555 Wiring Diagram Privacy Headset (optional) (4-pole, 3.5mm) Install Power AC/DC Power Adaptor (supplied) DC Power Lead (supplied) PotsDOCK BEAM iridium Ringer Track Bluetooth Mute ALERT Black 0V Ground to negative battery + VIN wire to the vehicle + Battery (3A fuse). -
Page 15: Use
Man Down Kit - F5 Installation & User Manual Emergency Alert Message Generation Pressing and holding the pendant button for more than 3 seconds until both LEDs blink green and orange will trigger an emergency alert notification message. The LEDS will continue to blink until the emergency alert is acknowledged. -
Page 16: Turning The Pendant On Or Off
Successful Acknowledgement 4 Vibrations 2 Escalating Sound Sequences Unsuccessful Acknowledgement 2 High then Low Sound Sequences When an alert notification message has been generated the left and right LED’s will both blink alternating between green and orange. This blinking will continue until the alert notification has been acknowledged, either with a successful acknowledgement or a unsuccessful acknowledgement. - Page 17 Man Down Kit - F5 Installation & User Manual ON WITH MOTION SENSING Double click within 1 second Double click within 1 second Triple click within 1 second Double click within 1 second Triple click within 1 second Triple click within 1 second LED’s provide an indication to the active mode of the device and there is an audible beep when the device is powered on or off.
-
Page 18: Physical Specifications
Physical Specification Man Down Pendant Mechanical Drawings 3.8 mm 37.1 mm 37 mm 90.4 mm 80.2 mm 33.24 mm 16mm [ .6 mm] NOTES WEIGHT: 50 grams HOUSING MATERIAL: PC/ABS Windshield Gateway Mechanical Drawings 95.01 mm 32.55 mm DB-9 27.63 mm RESET HOLE (UNDER EDGE OF ADHESIVE TAPE) ADHESIVE TAPE NOTES:... -
Page 19: Specification And Aprovals
The pendant has been tested to comply with regulations for license free operation in 2.4GHz band (FCC Title 47, Part 15, Sub part 247) Technical Support/Warranty: The Beam website provides product support information including: News and Releases Resources Software tools... -
Page 20: Assuring Quality Of Iridium Service
Assuring Quality of Iridium Service Iridium is committed to providing subscribers around the world consistent, reliable, quality voice and data access all day every day. The Iridium satellite system is monitored for call performance from numerous locations 24 hours, 7 days a week in order to achieve this. There are conditions that can compromise the quality of the service you may receive. -
Page 21: Rf Interference
Man Down Kit - F5 Installation & User Manual RF Interference All wireless devices, including satellite telephones, are susceptible to RF (radio frequency) interference from other electronic devices. This problem is more evident when numerous antennas and broadcasting devices are located within close proximity to each other. Symptoms of RF Interference Symptoms of RF interference often resemble those that arise when an Iridium phone is being operated with an obstructed view of the sky. -
Page 22: Beam Warranty Conditions
The Customer’s sole and exclusive remedy and the limit of Beam’s liability for any loss whatsoever, shall not exceed the purchase price paid by the Customer for the product to which a claim is made. - Page 23 Beam Communications unless otherwise stated in writing. If a product has been tampered with (e.g.; warranty seal has been removed, wrong cable has been used with an antenna), the warranty will be void.
- Page 24 WEB: www.beamcommunications.com EMAIL: info@beamcommunications.com PHONE: +61 3 8588 4500 FAX: +61 3 9560 9055 AFRICA | ASIA | AUSTRALIA | EUROPE | MIDDLE EAST | NORTH AMERICA | SOUTH AMERICA...
