- Page 1 WIRELESS REMOTE CONTROLLER KIT INSTALLATION MANUAL Installation manual Manuel dinstallation Manuel dinstallation Manual de instalación MODELS BRC082A41W BRC082A42W BRC082A42S...
- Page 2 BRC082A41W BRC082A42W BRC082A42S BRC082A41W BRC082A42W BRC082A42S Figure 1 X24A Figure 2 TEMP TEMP TIME TIME SETTING SETTING DOWN DOWN RESERVE CANCEL RESERVE CANCEL TIMER TIMER MODE MODE SWING SWING /TEST /TEST Figure 3 Figure 4...
-
Page 3: Table Of Contents
Installation of the decoration panel ....... of this kit. Installation of the receiver in case of BRC082A41W ..• Ensure that nothing interrupts operation of the Installation of the receiver in case of BRC082A42W/S .. -
Page 4: Remote Controller Installation
Remote controller installation Setting procedure Installing the wireless remote controller Setting the transmitter board „ Do not throw the remote controller or subject it to powerful Set the wireless address switch (SS2) on the transmitter shocks and do not store the remote controller where it may board according to the table below. -
Page 5: Installation Of The Transmitter Board
Affix the unit number label Display setting A/ Affix corresponding unit number labels onto both air outlet of The wireless remote controller has 2 possible display settings. the decoration panel and onto back of the wireless remote The standard setting A permanently indicates all operational controller. -
Page 6: Installation Of The Receiver In Case Of Brc082A41W
Installation of the receiver in case of BRC082A41W 1 Remove the suction grille as described in the installation manual supplied with the decoration panel. 2 Detach the brand name plate part of the decoration panel piece, before attaching the decoration panel. -
Page 7: Field Setting
Field setting 4 Pass the wire harness through the hole and insert the cover into its position and screw it. If optional accessories are mounted on the indoor unit, the indoor unit setting may have to be changed. Refer to the instruction manual (option handbook) for each optional accessory. - Page 8 Example If the time to clean air filter is set to “Filter Contamination-Heavy”, set Mode No. to “10”, First code No. to “0”, and Second code No. to “02”. First Second code No. Mode code Description of setting Sets operation time until AIR FILTER CLEANING TIME INDICATOR lamp Long-life ±2,500...
