Check to be sure you received the parts identified in Figure 1. If any part of the product appears damaged, do not attempt to use it. Notify Bose customer service immediately (see phone numbers on the inside back cover).
Selecting a location for your music system and changer The Acoustic Wave music system. Before you connect the two, however, select a good location for the stacked units. CAUTION: Setting up the two units separately (on different shelves of an entertainment cen- ter, for example) is not recommended.
Setting Up Connecting the multi-disc changer to your Acoustic Wave On the back of the multi-disc changer there are two cables (Figure 3) that connect to your Acoustic Wave 1. Insert the two connectors of the AUX input cable into AUX IN jacks on the back of the Acoustic Wave red to red, and white to white.
Operating with one remote control The remote control included with your Acoustic Wave trol functions of both the multi-disc changer and your Acoustic Wave fore, we suggest you put away the remote that came with your Acoustic Wave system and use only this Acoustic Wave Notice that this remote (Figure 5) has buttons to play the multi-disc changer, the Acoustic ®...
Using Your Acoustic Wave Turning your complete system on and off To turn on both the changer and the Acoustic Wave button (Figure 6) on the changer console. Figure 6 Play/Pause button on the ® Acoustic Wave multi-disc changer console that turns on both the changer and the Acoustic Wave ®...
When the multi-disc changer is playing, its display shows which disc and track are playing and the elapsed time. Using Your Acoustic Wave LED indicators ® Acoustic Wave music system display VOLUME Presets Volume Seek/Tune Acoustic Wave Music System On/Off CD Play/Pause Stop Skip/Scan CD Mode ® multi-disc changer display DISC TRACK CHANGER...
Using Your Acoustic Wave Playing the multi-disc changer Use buttons on the multi-disc changer remote or console, as shown below. Function To play the selected CD... Results: • If there is no CD in the slot, the word “DISC” flashes on the multi-disc changer display.
Function To change the mode of CD play... Press again to cycle through the choices, which appear on the console display. • REPEAT ALL • REPEAT ALL RANDOM • REPEAT DISC • REPEAT DISC RANDOM Playing the other sound sources The light blue buttons (Figure 9) on the multi-disc changer remote turn on the Acoustic Wave music system and select a sound source.
Not available Not available Play/Pause Not available AUX2 AUX1 AUX 2 ® music VOLUME Presets Volume Seek/Tune Acoustic Wave Music System On/Off CD Play/Pause Stop Skip/Scan CD Mode ON/OFF Next Disc CD Mode System control panel On/Off Not available CD Mode...
Note: If your component is mono, or does not include an RCA output cable, you may need to purchase an adaptor. Call Bose 1. Insert both connectors at one end of that cable into AUDIO OUT jacks on the rear of the component (Figure 10).
AC power outlet. Playing an auxiliary component Note: To play a component connected to the changer, you must first turn the component on. Neither of the Bose settings or selections. With the component turned on, select it using the Acoustic Wave control.
Mishandling the remote control battery may cause a fire or chemical burn. Keep the battery away from children. Do not recharge, disassemble, heat above 212˚F (100˚C), or incinerate the battery. Dispose of the used battery promptly and responsibly. For more information, call Bose back cover of this guide. Maintaining Your System Positive symbol ®...
LEDs is lit Customer Service For additional help in solving problems, contact Bose list on the inside back cover of this guide. ® multi-disc changer or a component connected to it is playing, make ®...
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. BOSE CORPORATION’S MAXIMUM LIABILITY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID BY YOU FOR THE PRODUCT. IN NO EVENT SHALL BOSE BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES. This warranty does not cover a defect that has resulted from improper or unreasonable use or maintenance, accident, improper packing, or unauthorized tampering, alteration, or modifica-...
1-800-637-8781 USA & Canada Service Bose Corporation, The Mountain Framingham, MA 01701-9168 1-800-637-8781 or 508-879-7330, x63055 European Office Bose Products B.V., Nijverheidstraat 8 1135 GE Edam, Nederland 0299-39011155 FAX 0299-390114 Australia Bose Pty Limited Unit 3/2 Holker Street Newington NSW, 2127...
