Dispose of the used battery promptly and responsibly. Please read this owner’s guide Please take the time to follow this owner’s guide carefully. It will help you set up and operate your Acoustic Wave ® multi-disc changer properly, and enjoy all of its advanced features. Save your owner’s guide for future reference.
• Hours of uninterrupted CD play • New multi-disc remote control, that provides simplified, all-in-one system operation • One button press turns on the changer, FM or AM radio or CD, or selects an auxiliary com- ponent • Compact design that complements the lines of your Acoustic Wave ®...
CD cover on top of the music system to open. • The music system should be near the horizontal center of a wall and 6 inches (15 cm) or less from the surface behind it.
Acoustic Wave ® music system. 1. Insert the two connectors of the AUX input cable into AUX IN jacks on the back of the ® Acoustic Wave music system. Be sure to match the colors of the connectors and jacks: red to red, and white to white.
Play/Pause for multi-disc changer Note: If the remote stops operating or its range seems reduced, it may be time to replace the battery. However, be aware that a change in room lighting or other conditions, in addition to battery age, can affect the operating range of an infrared remote control.
CD selected, the track it is playing, and the elapsed time. 1. To insert a CD into the changer, slip one edge of the disc into an empty slot and press on the opposite edge until the disc is all the way in (Figure 7 on page 9).
CD is inserted Note: To keep track of the order of CDs in the slots, you may find it useful to keep the CD cases stacked in the same order near the multi-disc changer.
AWMDC_OG.book Page 10 Monday, May 5, 2003 11:03 AM ® Using Your Acoustic Wave Multi-Disc Changer Playing the multi-disc changer Use buttons on the multi-disc changer remote or console, as shown below. AUX 1 AUX 2 ON/OFF Play/Pause Stop Next Disc...
Playing the other sound sources ® The light blue buttons (Figure 9) on the multi-disc changer remote turn on the Acoustic Wave music system and select a sound source. Those buttons include FM, AM, AUX1, AUX2, and CD (for the single-disc player in the Acoustic Wave ®...
® Note: For details on how the Acoustic Wave music system functions and the options avail- able for controlling it, refer to the owner’s guide that came in the carton with the system. VOLUME Presets Acoustic Wave Music System...
Call Bose Product and Technical Services,1-800-367-4008, for details. 1. Insert both connectors at one end of that cable into AUDIO OUT jacks on the rear of the component (Figure 10). 2. Insert both connectors at the other end of the cable into one pair of AUX jacks on the multi-disc changer.
1. Plug one end of the stereo audio cable into the output jacks of the preamplifier. 2. Plug the other end of the cable into one set of AUX IN jacks on your changer, matching red to the red jack marked R (right) and black or white to the white jack marked L (left).
Maintaining Your System Replacing the remote control battery If your remote control does not work properly, or its range of operation is reduced, it is time to replace the battery. Follow the instructions below: 1. Place the remote control face down on a flat surface.
® music system display. If it is not, press the AUX button on the music system console. • Make sure there is a CD is in the selected changer slot or in the CD player on the Acoustic Wave ®...
This warranty does not cover a defect that has resulted from improper or unreasonable use or maintenance, accident, improper packing, or unauthorized tampering, alteration, or modifica- tion as determined solely by us. This warranty is void if the label bearing the serial number has been removed or defaced.
AWMDC_OG.book Page 19 Monday, May 5, 2003 11:03 AM Bose Corporation USA & Canada Sales Bose Corporation, The Mountain Framingham, MA 01701-9168 1-800-637-8781 USA & Canada Service Bose Corporation, The Mountain Framingham, MA 01701-9168 1-800-637-8781 or 508-879-7330, x63055 European Office Bose Products B.V., Nijverheidstraat 8...
