Material Specification Arl - Flowserve ARL Technical Manual

Ahaus GmbH
von-Braun-Straße 19a
D-48683 Ahaus
Postfach 1162 D-48661 Ahaus
Telefon: +49(0) 2561-686-100
Fax: +49(0) 2561-686-200
No. Designation
010 body
020 bonnet
030 ball
040 stud bolt
050 hexagon nut
060
flut gasket
°
optional
Technical Manual

Material specification ARL

Pieces Material
1 ductile iron / PFA °
ductile iron / FEP °
1 ductile iron
1 PTFE - solid ball
4 stainless steel
4 stainless steel
1 PTFE
ARL - atomac check valve
Register:
Page:
Date:
Revision:
Material-No. / DIN
EN-JS1049 (GGG-40.3) /
DIN EN 1563
GGG-40.3 / DIN EN 1563
DIN EN 1563
pure - PTFE
1.4301 / DIN EN 10088-3
1.4301 / DIN EN 10088-3
14
4
02.1998
10.2008
ASTM / AISI
A 395
A 395
A 193 B8
A 193 B8
