Technical Manual
Technical Data ARL (ANSI)
DN / ANSI L
mm 160
1"
inch 6,3
mm 200
1½"
inch 7,87
mm 230
2"
inch 9,06
mm 310
3"
inch 12,2
Face-to-Face Dimension:
Flange Connection:
Tightness test:
ARL - atomac check valve
weight
H
90 kg 4,8
3,54 lbs 10,6
126 kg 9,2
4,96 lbs 20,3
136 kg 12,2
5,35 lbs 26,8
206 kg 20,5
8,11 lbs 45,2
DIN EN 558 (Basic series 1)
ANSI B 16.5 - CL150
DIN EN 12266-1 (leak rate B)
Register:
14
Page: 3
Date: 02.1998
Revision: 10.2008
