Quark-Elec G022P Setup Manual

G022P

ADDING ADDITIONAL MOBILE NUMBERS

You can add up to three additional control mobile phones.
When adding additional numbers to the unit you must enter
them in the correct format used by the Network service pro-
vider of the SIM that you have entered into the G022.
For example, if the UK number 07123456789 needs adding, we
have three formats to try (Using the UK country code '44').
1. +447123456789 2. 00447123456789 3. 07123456789
The most commonly used, is format 1, this will work with most
countries and providers. To store your number, text
'BD1+447123456789F' to the device. If you are able to send
commands from the new number but do not receive messages
back, try one of the other formats.
QK-G022P
Batteries: The PIR device uses a 9.0V D-shape battery.
Location: Think about location of sensor and whether there is anything in between the PIR
sensor and the G022P. Some obstructions will make the signal weaker for example metal
structures and concrete walls.
The PIR acts as input 3 and will activate relay 3.
Disclaimer
It is the user's responsibility to use this product prudently. Neither Quark-elec, nor their distributors or
dealers accept responsibility or liability either to the product user or their estate for any accident, loss, injury
or damage whatsoever arising out of the use or of liability to use this product.
Email: info@quark-elec.com
Web: www.quark-elec.com
V1.0(8/18)
G022P
GSM REMOTE CONTROLLER
SET-UP GUIDE


What You Need


Installation Overview


Notes

All products are CE, RoHS certified
www.quark-elec.com
Please recycle your packaging
