LOOP FAN
Ø100, Ø125
Operating and Assembly
Instructions.
You should read these operating and
assembly instructions and keep it
available for further use.
WARNING: Important safety
notes:
•
The fan can only be assembled by a quali ed
specialist electrician, in compliance with the
applicable mounting regulations.
•
Electrical installation must have a switch with at
least 3 mm distance between contacts.
•
Before assembly or maintenance equipment
power supply should be switched o and secured
against accidental activation.
•
This range of fans is only for domestic, business
use (restaurant kitchens, garages, etc.), they cannot
be used for industrial purposes.
•
Connecting the fan to the electrical installation
and its mounting should be performed in
compliance with the applicable national mounting
regulations.
•
The fans can be operated in air temperature
between 0 and 40 °C.
EN
Advertisement
Table of Contents
Related Manuals for AirTechnic LOOP WL100
Summary of Contents for AirTechnic LOOP WL100
- Page 1 LOOP FAN Ø100, Ø125 Operating and Assembly Instructions. You should read these operating and assembly instructions and keep it available for further use. WARNING: Important safety notes: • The fan can only be assembled by a quali ed specialist electrician, in compliance with the applicable mounting regulations.
- Page 2 • The fan cannot be operated when there is a risk of foreign objects getting to the air stream of the fan. They can damage moving parts of the device or cause it to jam. • Fans should be installed in ventilation ducts free from any exhausts, other gases, or aggressive agents.
- Page 3 - depending on the model. Fan models and accessories: LOOP WL100, WL125 (Standard): the fan is equipped with a block to connect it to power supply. Speed control is manual - after turning on/o a separate switch or a perimeter light switch.
- Page 4 INDEX Ø LOOP WL100 100 LOOP WL125 125 LOOP MODEL DESIGN (Fig.1) LOOP series extraction fan includes body 1 with mounted motor and propeller. Control plate is mounted in the central ow section (protected by cover 3, mounted with screws 4). Part 5 is xed to the front part of the body and serves to insert the power supply cable.
- Page 5 • mount the body by driving the screws in the anchors • connect power cables to the mounted fan according to the connection diagram of a particular model (Fig.2) • mount the control plate cap, drive the screws, place the cable cover •...
