PR -6000 Manual

Spot 2000w version
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PR-6000 Spot(2000W version)
PR-2960
The user manual contains important information about the safe installation and use of a projector. Please read and
follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR-6000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR PR-6000

Summary of Contents for PR PR-6000

  • Page 1 PR-6000 Spot(2000W version) PR-2960 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.

  • Page 2: Table Of Contents

    Any future technical change in the user manual won’t be with any notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty...

  • Page 3: Safety And Warnings

    1.SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Goggles Protective High Warning Flames Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.

  • Page 4: Instructions

    There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord ● supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from power ●...

  • Page 5: Troubleshooting

    TROUBLESHOOTING ● PROBLEM ACTION  Check the fuse on the power socket. The projector doesn’t switch on  Check the lamp. The lamp is on but the projector doesn’t respond  Make sure that the fixture’s start address is right ...

  • Page 6: Power Connections

    CLAMP WARNING TO pass 2 SAFETY CORDS through 4 HOLES for safety HOLES for SAFETY CORDS CONTROL HANDEL PANEL Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp.

  • Page 7: Dmx Control Connections

    ●DMX CONTROL CONNECTION: Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.

  • Page 8: Gobo Replacement

    “INSTRUCTIONS” packed with the lamp. Lamp Fast fit screws Lamp cover Don’t touch the internal surface of the reflector and the burner of the lamp with bare hands so as not to impair the beam output. While ● lamp’s installation, do not damage the metal wire around the burner. Please read "Instructions "...

  • Page 9: Setup And Configuration

    5.SETUP AND CONFIGURATION FRONT PANEL OPERATION ● The projector configuration can be set conveniently via push buttons and color touch screen. To browse through or change the projector ’s settings, touch the white area of the touch screen or press OK button for more than 3s(Only ►...

  • Page 10: Master/Slave Mode

    Pan&Tilt Reset Really Reset? Colour System Reset Really Reset? Reset Gobo Reset Really Reset? Dimmer/Strobe reset Really Reset? Zo.Fo.Fr.Pr. Reset Really Reset? Other Reset Really Reset? Short Mode DMX Channel Mode Standard Mode Extended Mode View Selected Mode Config Settings...
  • Page 11 XLR First Wireless Only Wireless First Wireless In/XLR Out ARTNET Only ARTNET/XLR Out Normal time out Loss of DMX Hold Last Value Off After Delay Display Mode On Always Invert OFF Display Config Display Invert Invert ON Invert Auto English Language Setting Chinese Input Password123...

  • Page 12: Dmx Protocol

    System= XXX Driver Board 1 Boot =XXX System= XXX Driver Board 2 Boot =XXX System= XXX Driver Board 3 Boot =XXX System= XXX Driver Board 4 Boot =XXX Electronic SN= Electronic SN ************ RDM Device Label RDM Device Label ANSI E1.20 RDM Version X.X Fan Status Base Fan...
  • Page 13 Close Linear dimmer (0-100%) Dimmer in 16 bit Dimmer in 16 bit adjustment CYM macros The following functions will disable CMY,CTO, color wheel No function Color macro1 Color macro2 Color macro3 Color macro4 Color macro5 Color macro6 Color macro7 Color macro8 Color macro9 Color macro10 Color macro11...
  • Page 14 Color macro38 Color macro39 Color macro40 Color macro41 Color macro42 Color macro43 Color macro44 Color macro45 Color macro46 Color macro47 Color macro48 Color macro49 Color macro50 Color macro51 Color macro52 Color macro53 Color macro54 Color macro55 Color macro56 Color macro57 Color macro58 Color macro59 Color macro60...
  • Page 15 Color macro82 Color macro83 Color macro84 Color macro85 Color macro86 Color macro87 Color macro88 Color macro89 Color macro90 Color macro91 Color macro92 Color macro93 Color macro94 Color macro95 Color macro96 CMY color mixing fade from slow toast Cyan Cyan (Linear 0-100%) Cyan in 16 bit Cyan 16 bit adjustment Yellow...
  • Page 16 Color4()/Color5() Color5() Color5()/Color6() Color6() Color6()/ Color7() Color7() Color7()/White White Clockwise rainbow effect from slow to fast Anti-clockwise rainbow effect from slow to fast Color wheel in 16bit Color wheel continuous positioning ,16bit adjustment Iris Linear iris from big to small Iris in 16bit Iris 16 bit adjustment Iris macros...
  • Page 17 White Gobo1 Gobo2 Gobo3 Gobo4 Gobo5 Gobo6 Clockwise rotation from slow to fast Anti-clockwise rotation from slow to fast Gobo1 shakes from slow to fast Gobo2 shakes from slow to fast Gobo3 shakes from slow to fast Gobo4shakes from slow to fast Gobo5shakes from slow to fast Gobo6shakes from slow to fast Gobo rotation 1...
  • Page 18 Stop Anti-clockwise rotation from slow to fast Gobo rotation 2 in 16bit Gobo rotation2 16bit adjustment Prism Prism in Prism rotation Prism indexing Stop Clockwise rotation from slow to fast Stop Anti-clockwise rotation from slow to fast Effect wheel Effect wheel in Effect wheel rotation Clockwise rotation from fast to slow Anti-clockwise rotation from slow to fast...

  • Page 19: Signs On The Touch Screen

    than 5s to activate it 2.The lamp can be turned off 5minutes after it is on, And the lamp can be turned on 5 minutes after it is off. 3.to turn on or turn off the lamp, keep lamp control-DMX control signal as ON Display on Display off...

  • Page 20: Error Message

    9.ERROR MESSAGE The system can detect some errors during the reset, if displayed, touch to view the error. The error messages are as follows: Name Type Correction Timeout/magnet Sensor/Encoder Check if wiring, positioning parts and motors are normal Timeout/magnet Sensor/Encoder Check if wiring, positioning parts and motors are normal Tilt Timeout...

  • Page 21: Technical Data

    10.TECHNICAL DATA ELECTRIC PARAMETERS ，50/60Hz Input voltage 200V~240V AC Input power 2450W@220V Power factor: PF>0.9 THE SPECIFICATIONS OF THE LIGHT SOURCE(WITH 2000W BALLAST AND IGNITER) lok-it 2000W/PS Philip Color temperature 6000K >90 lamp stand single ended rated life 750hrs COLORS CMY linear mixing system with macros 1 color wheel: 7colors+ Open, Half Color effect, rainbow effect with bi-directional and variable speeds,...
  • Page 22 GOBO 2 Rotating Gobo Wheel: 6 replaceable gobos+ White, Glass or Metal Gobo Bi-directional Rotation with variable speeds With Indexing Function Gobo Shake Effect with Variable Speeds Bi-directional Scrolling with Variable Speeds Rotating Gobo Wheel 1: 120150087 120150088 110010355 090070957 110010356 110010357 Rotating gobo Wheel2...
  • Page 23 FOCUS DMX linear Focusing DIMMER 0-100% Linear adjustment with two dimmer curves being linear and reverse squared law respectively of which the latter has wider range and is more smooth in diming in black places. IRIS 5-100% linear adjustment with macros STROBE Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT...
  • Page 24 Touch screen English and Chinese Display with Contrast and brightness adjustable Energy saving ballast Built-in sensor diagnostic system Built-in Chargeable battery and menu setting without power mains Input signal isolation Modular Structure for easy maintenance Ethernet Interface DMX512 wireless reciever Optional DMX512 Transmitter HOUSING High temperature ABS, IP20...

  • Page 25: Circuit Diagram And Pcb Connections

    LIGHT OUTPUT 55°（lux） 2106 125526 31384 13948 7846 5021 3487 6°（lux） 0 DISTANCE（m） 0m 6° DIAMETER（m） 0.57 1.14 1.71 2.28 2.85 3.42 55°DIAMETER（m） 0 5.22 10.43 15.65 20.86 26.08 31.30 11.CIRCUIT DIAGRAM AND PCB CONNECTIONS...

  • Page 27: Component Order Codes

    12 COMPONENT ORDER CODES NAME CODE NUMBER REMARKS SWITCHING POWER SUPPLY 192010136 POWER FILTER 193020014 THERMAL SWITCH 190010206 ELECTRONIC BALLAST (2000W) 040070132B LAMP （OSRAM 2000W） 100070054 IGNITER 040090066 TILT BELT 290151205 PAN BELT 290151207 LAMP FAN1 030060117 LAMP FAN 2 030060119 HEAD FAN 030060119...
  • Page 28 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N:...
