USB 3.0 D
A
ISPLAY
DAPTER
USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Cablematic USB 3.0 DISPLAY ADAPTER

Summary of Contents for Cablematic USB 3.0 DISPLAY ADAPTER

  • Page 1 USB 3.0 D ISPLAY DAPTER USER MANUAL...

  • Page 2: Table Of Contents

    ONTENTS ....................3  NTRODUCTION ....................3  EATURES ................3  YSTEM EQUIREMENTS ......................4  OTES ................4  ACKAGE ONTENTS ......... 4  UPPORTED OMMON ISPLAY ESOLUTION ..............5  ECHNICAL PECIFICATIONS ............... 5  UICK NSTALLATION UIDE 10/8.1/ 8/ 7 ............. 7  NSTALLATION ON INDOWS ...............

  • Page 3: Introduction

    USB 3.0 D ISPLAY DAPTER ANUAL NTRODUCTION Thank you for purchased the USB 3.0 D . By 10 times faster than USB ISPLAY DAPTER 2.0, the USB 3.0 D provides a unique solution to add an extra display ISPLAY DAPTER for your computer just plug and play.

  • Page 4: Notes

    USB 3.0 D ISPLAY DAPTER ANUAL OTES  Driver update and installation are available from Windows update via an active network connection.  Do not recommend to connect USB 3.0 D via the external USB ISPLAY DAPTER Hub.  System reboot is required for the driver installation. ...

  • Page 5: Technical Specifications

    USB 3.0 D ISPLAY DAPTER ANUAL ECHNICAL PECIFICATIONS Windows 10/ 8.1 / 8 / 7 / XP (32bit &64bit) Operating System Mac Snow Leopard (10.6) / Lion (10.7) / Mountain Lion (10.8) / Mavericks (10.9) / Yosemite (10.10) / EI Capitan (10.11) Host Interface USB 3.0 A type connector...
  • Page 6 USB 3.0 D ISPLAY DAPTER ANUAL ※When the Windows OS is Windows XP or there is no network connection  Insert the Driver/Manual CD into CD-ROM drive; the setup program should be launched automatically. Or, double click “D:\Setup.exe (where D: is the path of your CD-ROM drive) and follow the instructions to install the device driver.

  • Page 7: Installation On Windows 10/8.1

    USB 3.0 D ISPLAY DAPTER ANUAL 10/8.1/ 8/ 7 NSTALLATION ON INDOWS EVICE RIVER NSTALLATION Installing the device driver enables your computer’s operating system to recognize the USB 3.0 D once it’s connected. Please check your operating system ISPLAY DAPTER and refer to the appropriate installation procedure to begin installing the device driver.
  • Page 8 USB 3.0 D ISPLAY DAPTER ANUAL License Agreement; please review it and check “I accept the terms of the license agreement.” Click “Next” to accept the License Agreement. Step 4. Setup is searching for installed features..Step 5. Select “Yes, I want to restart my computer now”, and click “Finish” to reboot.
  • Page 9 NSTALLATION OF MULTIPLE ISPLAY DAPTERS Please plug in the additional USB 3.0 Display Adapter (connected with the external display device already) to an available USB port of your computer (host PC), the device driver will be configured automatically. After the driver is configured completely, the USB extended display will be shown on the attached display device.

  • Page 10: Verifying Device Driver Installation (Windows 8.1)

    , then double click “Trigger USB Graphics ISPLAY DAPTER Family”. Begin verification by make sure highlighted devices were added to the system.  Single USB 3.0 Display Adapter installation on the computer USB 3.0 TO VGA/DVI USB 3.0 TO HDMI...
  • Page 11 USB 3.0 D ISPLAY DAPTER ANUAL  Multiple USB 3.0 Display Adapters installation on the computer...

  • Page 12: Device Driver U N - Installation

    USB 3.0 D ISPLAY DAPTER ANUAL EVICE RIVER INSTALLATION Step 1. Rick click “Start” at the taskbar, then click →”Programs and Features”. Select “ Trigger External Graphics Family 15.xx.xxxx.0179”. Click “Uninstall” button. Step 2. Unplug the USB 3.0 D and click “OK” to continue. ISPLAY DAPTER Step 3.

  • Page 13: Installation On Windows Xp

    USB 3.0 D ISPLAY DAPTER ANUAL NSTALLATION ON INDOWS EVICE RIVER NSTALLATION Installing the device driver enables your computer’s operating system to recognize the USB 3.0 D once it’s connected. Please check your operating system ISPLAY DAPTER and refer to the appropriate installation procedure to begin installing the device driver. This section illustrates the simple device driver installation procedure for computer running Windows XP operating system.
  • Page 14 USB 3.0 D ISPLAY DAPTER ANUAL Step 3. License Agreement; please read it and select “I accept the terms of the license agreement.” Click “Next” to accept the License Agreement. Step 4. Setup is searching for installed features….. ※ You may notice the screen flashes during the driver installation. It is part of the normal process.
  • Page 15 ” on taskbar. The extended display will be shown on the attached display device. The USB 3.0 Display Adapter is ready to use now. ※ You may notice the screen flashes during the hardware installation. It is part of the...
  • Page 16 NSTALLATION OF MULTIPLE ISPLAY DAPTERS Please plug in the additional USB 3.0 Display Adapter (connected with the external display device already) to an available USB port of your computer (host PC), the device driver will be configured automatically. After the driver is configured completely, the USB extended display will be shown on the attached display device.

  • Page 17: Erifying Evice River Nstallation Indows Xp)

    USB 3.0 D ISPLAY DAPTER ANUAL ERIFYING EVICE RIVER NSTALLATION INDOWS The following procedure allows you to verify the device driver installation. Please right click “My Computer” → “Properties” → “Hardware” → “Device Manager”. Plug-in the USB 3.0 D , then double click “Display adapters”, and ISPLAY DAPTER “Trigger USB Graphic Family”.

  • Page 18: Device Driver U N - Installation

    USB 3.0 D ISPLAY DAPTER ANUAL EVICE RIVER INSTALLATION Step 1. Click “Start” → “Control Panel” → “Add or Remove Programs” Select “ Trigger External Graphics Family 15.xx.xxxx.0179”. Click “Uninstall” button. Step 2. Unplug the USB 3.0 D and click “OK” to continue. ISPLAY DAPTER Step 3.

  • Page 19: Function Description

    USB 3.0 D ISPLAY DAPTER ANUAL UNCTION ESCRIPTION This section describes several friendly functions provided by the USB D ISPLAY designed to ease your single or multiple USB display experience. A display DAPTER device described in this section means devices such as monitor and projector... USB D 7/ 8/ 8.1/10) CCESS...
  • Page 20 USB 3.0 D ISPLAY DAPTER ANUAL ISPLAY ESOLUTION – Fast Access to Display Resolution Setting The resolution list will show up when you move the cursor over “Display Resolution”. Select and click the resolution you want. ISPLAY RIENTATION There are four options available: “Landscape”, “Portrait (Flipped)”, “Landscape (Flipped)”, and “Portrait”...
  • Page 21 USB 3.0 D ISPLAY DAPTER ANUAL ISPLAY  “E ” (D XTEND ESKTOP EFAULT A default display mode, this feature allows the attached USB Display enable display device to work as “Extended” display of the on-board screen.  “D ” UPLICATE ESKTOP This feature allows the same contents of on-board...
  • Page 22 USB 3.0 D ISPLAY DAPTER ANUAL  “P ” LAY BACK EVICE Fast open to the system “Sound”. The USB Audio is the default audio output when connects with USB HDMI Display Adapter.  “S ” CREEN ESOUTION Fast access to the “Screen Resolution”. ...

  • Page 23: Q&A

    USB 3.0 D ISPLAY DAPTER ANUAL Q&A This section describes the common Q&A regarding to the installation or operation of the 3.0 D ISPLAY DAPTER Q: Why can’t I make the USB 3.0 D the primary display? ISPLAY DAPTER A: Some video cards ship their product with a utility that prevent other video cards from being set as the primary card.

  • Page 24: Troubleshooting Tips

    USB 3.0 D ISPLAY DAPTER ANUAL ROUBLESHOOTING This section describes the general troubleshooting tips regarding to the installation or operation of the USB D ISPLAY EVICE Known Issues - It is prohibited to install the other USB to Graphics drivers (example: DisplayLink software) at the same Windows operating system.

  • Page 25: Others

    USB 3.0 D ISPLAY DAPTER ANUAL - Windows Media Player 10 or above - Media Player Classic: http://sourceforge.net/projects/guliverkli/ Others - Some graphics card, i.e. Intel, prevents other secondary graphics chipset from being set as the primary card. As the result of this, Primary mode might not work or the display maybe disabled. - If you have problems during the boot up process, start your computer in Safe Mode and uninstall the driver.

  • Page 26: Regulatory Compliance

    USB 3.0 D ISPLAY DAPTER ANUAL EGULATORY OMPLIANCE This equipment has been tested and found to comply with FCC 47 CFR PART 15 SUBPART B (Class B) & IC ICES-003. Operation is subject to the following two conditions: • This device may not cause harmful interference •...
