PROGRAMMING YOUR DRONE

ABOUT THE TOURNEY LOCK

The board is equipped with a tourney lock system. When the tourney lock system is acti-
vated, the marker cannot be reprogrammed on the field - making it tournament legal.
To use the tourney lock, you must remove the three screws holding the right hand side of
the wrap around grip on your frame. On the board, there is a small button. To toggle the
tourney lock, hold this down. The board will flash red/green, and then end on either red or
green. This ending colour indicates the state of the tourney lock:
Red: Tourney lock on
Green: Tourney lock off
Once you have finished with the tourney lock, replace the wrap around grip and screws
before playing.

PROGRAMMING THE SOFTWARE

To program the board, turn the marker off. Hold down the trigger whilst turning the marker
on. The indicator light will turn white, continue to hold the trigger until it goes blue (de-
bounce register). Press the trigger once to advance to the next setting as given below. When
you have a setting you would like to change, hold the trigger until the indicator light goes
out. Release the trigger, and the indicator light will flash to show the current setting. Then
when it goes out, input the new setting by the trigger and wait for the indicator light to go
solid again.
Register Summary Table
LED Colour Setting
Blue Debounce (1/2ms increments)
Red Dwell (1ms increments)
White
Green
Yellow
Teal
Purple
Flickering Blue
Flickering Red
Flickering White
Flickering Green
Flickering Yellow

DEBOUNCE (BLUE)

The debounce setting of your marker is used to control the amount of "bounce" in your
trigger. A very low debounce setting will result in a lot of bounce. In some tournaments
or fields, it will be necessary to reduce the amount of bounce by increasing the debounce
setting. Always increase the debounce slowly, because settings higher than 15 will result in
your marker feeling unresponsive.

DWELL (RED)

The dwell setting controls the amount of time that your solenoid is held open. A very low
dwell will result in very poor performance from your marker, whilst a very high value will
result in a very slow maximum rate of fire and excess air usage.
Default
10

FIRE MODE (WHITE)

16
Your marker is equipped with 8 different fire modes. These fire modes will allow you to
Fire mode
Max ROF - only used in capped and ramp
modes
Loader delay (1/2ms increments)
Anti Mechanical Bounce
Anti Bolt Stick
Factory Setting
Cycle filter
Eye Mode
Bolt Tracking Delay (ms)
Test Mode Dwell (ms)
1 (semi)
5 (10bps)
2
2
3
-
2
2 (forced
shot)
10
2
