Connect the Hardware
If your Internet connection is through an Ethernet cable from the wall instead of through a DSL/Cable/Satellite
modem, connect the Ethernet cable directly to the router's Internet port, and skip Step 2,3,5 to complete the
hardware connection.
Power adapter
Modem
1
INTERNET
2
Power adapter
5
3
1
4
* Illustrative image used for reference
Router*
