  • Page 1 TVÄTTAD...
  • Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Troubleshooting Control panel Consumption values Programmes Environmental concerns Settings IKEA guarantee Daily use Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage.
  • Page 5 ENGLISH If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user maintenance • of the appliance without supervision. General Safety Do not change the specification of this appliance. • This appliance is intended to be used in household and •...
  • Page 6 ENGLISH The operating water pressure at the water entry point from • the outlet connection must be between 0.5 bar (0.05 MPa) and 8 bar (0.8 MPa). The appliance maximum load is 8 kg. Do not exceed the • maximum load of each programme (refer to the "Programmes"...

  • Page 7: Safety Instructions

    ENGLISH Never stop the washer dryer before the end of the drying • cycle unless all items are quickly removed and separated so that residual heat can dissipate. The final part of the washer dryer cycle takes place without • heat (cool down cycle) to ensure that items reach a temperature that will not cause damage to them.
  • Page 8 ENGLISH Electrical Connection • Do not touch the glass door while a programme operates. The glass can get Warning! Risk of fire and electric hot. shock. • Do not dry damaged (torn, frayed) items that contain padding or fillings. • The appliance must be earthed. •...

  • Page 9: Product Description

    Product description Appliance overview Detergent dispenser drawer Mod. TVÄTTAD Made in Italy Control panel PNC: 914580227 00 © Inter IKEA Systems B.V. 1999 1910 Type: FLI454341 704.334.42 230V ~ 50Hz Door handle 2200W IKEA of Sweden AB 21552 SE-343 81 Älmhult...

  • Page 10: Technical Data

    ENGLISH Technical Data Model name BWD TVAT 8 WH Dimension Width/ Height/ Total 59.6 cm /81.9 cm /55.3 cm depth Electrical connection Voltage 230 V Overall power 2000 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, except where the low voltage equipment has no protection...

  • Page 11: Inspection Check List

    Model (Mod.): ..... Art. No. Mod. Article number (Art.No.): ......Mod. TVÄTTAD Serial number (Ser.No.): ....... Made in Italy PNC: 914580227 00 © Inter IKEA Systems B.V. 1999 1910 Type: FLI454341 704.334.42 230V ~ 50Hz 2200W IKEA of Sweden AB 21552 SE-343 81 Älmhult...

  • Page 12: First Use

    ENGLISH First use 2. Pour 2 litres of water into the detergent During installation or before first use you may observe some water compartment marked by in the appliance. This is a residual This action activates the drain system. water left in the appliance after a 3.
  • Page 13 ENGLISH Press this button for a few seconds to activate or deactivate the appliance. Two different tunes sound while switching the appli‐ On/Off button ance on or off. As the Stand-by function automatically deactivates the appliance after several minutes to reduce the energy consumption, press this button to activate the appliance again.
  • Page 14 ENGLISH • Door locked indicator: – Indicator on: the door cannot be opened. The appliance is working or has stopped with water left in the tub. – Indicator off: the door can be opened. The programme is finished or the water has been emptied out. •...
  • Page 15 ENGLISH This button allows you to start or to pause the selected washing programme. Start/Pause touch button With this option you can delay the start of a programme to a more convenient time. Delay Start touch Touch the button repeatedly to set the required delay. The time button increases in steps of 1 hour up to 20 hours.
  • Page 16 ENGLISH Permanent Extra With this option you can permanently have an extra rinse when Rinse you set a new programme. To activate/deactivate this option, hold the button pressed for 3 seconds until the indicator comes on/goes off on the display. When it is activated, the appliance will default to this option after you switch it off or change/reset the programme.

  • Page 17: Programmes

    ENGLISH Multilingual badges Adhesive badges in different languages are supplied with the appliance. The desired badge can be glued around the programme knob. Programmes Programme Chart Programme Reference Max. Programme description Default temper‐ spin speed load (Type of load and level of soiling) ature Spin speed Temperature...
  • Page 18 ENGLISH Programme Reference Max. Programme description Default temper‐ spin speed load (Type of load and level of soiling) ature Spin speed Temperature range range (rpm) 1200 rpm 3 kg Synthetic and mixed fabrics. Normally soiled (1200 - 400) items. Mixed 30 °C 40 °C - Cold 1600 rpm...
  • Page 19 ENGLISH Programme Reference Max. Programme description Default temper‐ spin speed load (Type of load and level of soiling) ature Spin speed Temperature range range (rpm) 1200 rpm 3 kg Cottons and mixed fabrics. Lightly soiled items. (1200 -400) Optimal washing results and perfect fabric care in Express care a short time for your everyday laundry.
  • Page 20 ENGLISH Pro‐ gramme No spin ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Suitable detergents for each programme Programme Universal Liquid Univer‐ Liquid for col‐ Delicates Special oureds woollens powder ▲ ▲ ▲ ▲ ▲...
  • Page 21 ENGLISH Dryness Level Type of fabric Load Cottons and Linen up to 4 kg (bathrobes, bath towels, etc) Cupboard Dry For items to be stored Synthetics and mixed fab‐ up to 3 kg rics (jumpers, blouses, under‐ wear, household and bed lin‐ Delicate fabrics up to 2 kg (acrylics, viscose and delicate...

  • Page 22: Settings

    ENGLISH Dryness Level Type of fabric Load Spin Suggested du‐ (kg) speed ration (mins) (rpm) 1200 45 - 55 Delicates 155 - 165 (acrylics, viscose and delicate mixed 1200 fabrics) 1200 95 - 105 Wool 80 - 100 1200 (woollen jumpers) Denim garments 1200 155 - 165...
  • Page 23 ENGLISH Activating the appliance Warning! Washing heavily oiled, 1. Connect the mains plug to the mains greasy stains could cause damage socket. to rubber parts of the washing 2. Open the water tap. machine. 3. Press the On/Off button for a few seconds to activate the appliance.
  • Page 24 ENGLISH • REMOVE TO CLEAN = Remove to clean. For liquid detergent: • = Maximum. flap turned • SOFTENER = Softener. downwards. • MAX 100 ml = Max 100 ml. With the flap is in the Follow the product position for liquid manufacturer's recommendations detergent: on quantities to use and do not...
  • Page 25 ENGLISH 3. If desired, set one or more options by Changing the delay start after the touching the related buttons. The related countdown has started indicators illuminate. To change the delay start: If a selection is not possible an acoustic signal sounds and the 1.
  • Page 26 ENGLISH Important! If the laundry amount will not be If the AutoAdjust System has reduced, the washing programme starts completed and the water filling anyway, despite the overload. In this case, it has already started, the new will be not possible to guarantee the best programme starts without washing results.
  • Page 27 ENGLISH signals operate (if they are active). The 2. Press the Start/Pause button: the display shows appliance drains the water and spins. The option indicator goes off. The indicator of the Start/Pause button goes off. If you have set and the spin speed has not been changed, The door unlocks and the indicator goes...

  • Page 28: Daily Use - Washing & Drying

    ENGLISH Daily use - Washing & Drying The time value on the display is the Warning! Refer to Safety duration of both cycles washing and chapters. drying, calculated on a default load size. This appliance is an automatic To have a good drying by using washer dryer.

  • Page 29: Daily Use - Drying Only

    ENGLISH 1. Remove the laundry from the appliance. • Press the On/Off button for some 2. Make sure that the drum is empty. seconds to deactivate the appliance. After drying phase, clean the After some minutes from the drum, the seal and the inside of end of the programme, the the door with a wet cloth.

  • Page 30: Fluff In The Fabrics

    ENGLISH 1. Remove the laundry from the appliance. • The indicator of the Start/Pause 2. Make sure that the drum is empty. button goes off. The door locked After drying phase, clean the indicator goes off and the door unlocks. drum, the seal and the inside of •...
  • Page 31 ENGLISH • Be careful with curtains. Remove the powder detergents containing bleach hooks and put the curtains in a washing for whites and laundry sanitization, bag or pillowcase. – liquid detergents, preferably for low • Do not wash laundry without hems or temperature wash programmes with cuts.
  • Page 32 ENGLISH • With adequate pre-treatment, stains and Items not suitable for drying limited soiling can be removed; the Do not set a drying programme for this laundry can then be washed at a lower laundry: temperature. • Synthetic curtains. • To use the correct quantity of detergent, •...

  • Page 33: Care And Cleaning

    ENGLISH General Tips 1. Use fabric conditioner in the washing cycle. Refer to the «Drying programmes» table to 2. Use special fabric conditioner for tumble find the average drying times. dryers. Experience will help you to dry the laundry When the drying programme is completed better.
  • Page 34 ENGLISH Descaling Rust deposits in the drum may occur due to rusting foreign body in the washing or tap If the water hardness in your area water containing iron is high or moderate, we Clean the drum with special products for recommend that you use a water stainless steel.
  • Page 35 ENGLISH Clean the drain pump if: To aid cleaning, • The appliance does not drain the water. remove also the top • The drum does not turn. part of the additive • The appliance makes an unusual noise compartment. because of the blockage of the drain pump.
  • Page 36 ENGLISH 3. Turn the filter 180 180˚ degrees in anti- clockwise direction to open it, without 10. Close the pump removing. Let the cover. water flow out. 4. When the bowl is full of water, turn the filter back and empty When you drain the water with the the container.

  • Page 37: Troubleshooting

    ENGLISH 2. Start the programme to drain the water. • Unscrew the hose from the appliance. Frost precautions Keep a rag nearby because some water may flow. If the appliance is installed in an area where • Clean the filter in the valve with a stiff the temperature can reach values around 0°...
  • Page 38 ENGLISH • - No communication between electronic elements of the appliance. Switch it off and switch on again. The programme was not finished properly or the appliance stopped too early. If the alarm code appears again, contact the Authorised Service Centre. •...
  • Page 39 ENGLISH Problem Possible solution • Make sure that the drain hose is in the correct position. The The appliance fills with water and drains immedi‐ hose may be positioned too low. Refer to "Installation instruc‐ ately. tion". • Make sure that the sink spigot is not clogged. •...
  • Page 40 ENGLISH Problem Possible solution • The AutoAdjust System is able to adjust the programme du‐ The programme duration increases or decreases ration according to the type and the laundry load size. Refer during programme exe‐ to "The AutoAdjust System load detection" in "Daily Use" cution.

  • Page 41: Consumption Values

    ENGLISH 4. Take out the laundry and then close the Make sure that the water level appliance door. inside the drum is not too high. If necessary, proceed with an Service emergency drain (refer to «Emergency drain» in «Care We recommend the use of original spare and cleaning»...

  • Page 42: Environmental Concerns

    ENGLISH Programmes Load (kg) Energy con‐ Water con‐ Approximate pro‐ sumption sumption (li‐ gramme duration (mi‐ (kWh) tre) nutes) Cottons 60°C 1.23 Cottons Eco 60 °C Cottons energy saving pro‐ 0.97 gramme Cottons 40°C 0.89 Synthetics 40°C 0.59 Delicates 40°C 0.30 Wool/Handwash 30°C 0.15...

  • Page 43: Ikea Guarantee

    2021. Manufacturer: IKEA of Sweden AB, Box 702, 343 81 Älmhult, Sweden The entity authorized by the manufacturer to take actions in Russia for assessment of the conformity of products: OOO Electrolux Rus, Kozhevnicheskiy proezd 1, 115114, Moskva;...
  • Page 44 What is not covered under this this delivery will be covered by this guarantee? guarantee. • The conditions for the installation of IKEA • Normal wear and tear; appliances, except for the cases when • Deliberate or negligent damage, damage...
  • Page 45 Manual before contacting the service. How to reach us if you need our service Please refer to the last page of this manual for the full list of IKEA appointed service partners. In order to provide you with a quicker service, we recommend...
  • Page 46 Hétköznap 8.00 és 17.00 óra között 0900 - 235 45 32 ma-vr: 8.00 - 21.00 Nederland Geen extra kosten. (0900-BEL IKEA) zat: 9.00 - 21.00 Luxembourg 0031 - 50 316 8772 Alleen lokaal tarief. zon / pub. vakantie: 10.00 - 18.00...
  • Page 48 21552 © Inter IKEA Systems B.V. 2021 AA-2227001-3...
