Philips LC8.1E Service Manual

Colour television
Hide thumbs
Table of Contents

Advertisement

Quick Links

Colour Television
Contents
©
Copyright 2008 Koninklijke Philips Electronics N.V.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Published by TY 0872 BU TV Consumer Care
Page
2
5
6
7
23
24
25
26
27
28-30
31
32
Diagram PWB
(B01) 33
47-51
(B02) 34
47-51
47-51
47-51
(B04B) 37
47-51
(B04C) 38
47-51
47-51
(B05B) 40
47-51
47-51
47-51
(B06C) 43
47-51
(B06D) 44
47-51
45
46
52
54
Printed in the Netherlands
Contents
Subject to modification
Chassis
LC8.1E
LB
MG8
MG8
I_18170_000.eps
300708
Page
55
58
63
65
71
71
EN 3122 785 18171

Advertisement

Table of Contents
loading

Related Manuals for Philips LC8.1E

Summary of Contents for Philips LC8.1E

  • Page 1: Table Of Contents

    All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips. Published by TY 0872 BU TV Consumer Care...

  • Page 2: Technical Specifications, Connections, And Chassis Overview

    EN 2 LC8.1E LB Technical Specifications, Connections, and Chassis Overview 1. Technical Specifications, Connections, and Chassis Overview Index of this chapter: 1.1.3 Miscellaneous 1.1 Technical Specifications 1.2 Connection Overview Power supply: 1.3 Chassis Overview - Mains voltage (V : 220 - 240...
  • Page 3 Technical Specifications, Connections, and Chassis Overview LC8.1E LB EN 3 Connection Overview 4 - EXT2: CVBS - In/Out, Audio - In/Out E_06532_001.eps 75 Ω SERV. U 050404 TV ANTENNA Figure 1-2 SCART connector - Audio R 0.5 V / 1 kohm - Audio R 0.5 V...
  • Page 4 EN 4 LC8.1E LB Technical Specifications, Connections, and Chassis Overview 6 - S-Video (Hosiden): Video Y/C - In 9 - Cinch: Video YPbPr - In, Audio - In - Ground Y Gn - Video Y / 75 ohm - Ground C Bu - Video Pb 0.7 V...

  • Page 5: Safety Instructions, Warnings, And Notes

    • Use only lead-free soldering tin Philips SAC305 with order the mass of the set by a wristband with resistance. Keep code 0622 149 00106. If lead-free solder paste is required, components and tools also at this same potential.

  • Page 6: Directions For Use

    EN 6 LC8.1E LB Directions for Use 2.3.5 Alternative BOM identification MADE IN BELGIUM MODEL 32PF9968/10 It should be noted that on the European Service website, 220-240V 50/60Hz “Alternative BOM” is referred to as “Design variant”. 128W VHF+S+H+UHF PROD.NO: AG 1A0617 000001 BJ3.0E LA...

  • Page 7: Mechanical Instructions

    Mechanical Instructions LC8.1E LB EN 7 4. Mechanical Instructions Index of this chapter: 4.1 Cable Dressing 4.2 Service Positions 4.3 Assy/Panel Removal MG8 Styling 4.4 Set Re-assembly Notes: • Figures below can deviate slightly from the actual situation, due to the different set executions.
  • Page 8 EN 8 LC8.1E LB Mechanical Instructions I_18170_030.eps 300708 Figure 4-2 Cable dressing 42" sets Service Positions The foam bars (order code 3122 785 90580 for two pieces) can be used for all types and sizes of Flat TVs. See figure “Foam bars”...
  • Page 9 Mechanical Instructions LC8.1E LB EN 9 Assy/Panel Removal MG8 Styling 4.3.4 Keyboard Control Panel Refer to next figure for details. Pictures are taken from 32” set. 1. Unplug the key board connector from the IR & LED board. 2. Remove the screws [1].
  • Page 10 EN 10 LC8.1E LB Mechanical Instructions 4.3.6 Small Signal Board (SSB) Refer to next figure for details. Caution: it is mandatory to remount all different screws at their original position during re-assembly. Failure to do so may result in damaging the SSB.
  • Page 11 Mechanical Instructions LC8.1E LB EN 11 I_18170_053.eps 310708 Figure 4-10 LCD Panel -2- Set Re-assembly To re-assemble the whole set, execute all processes in reverse order. Notes: • While re-assembling, make sure that all cables are placed and connected in their original position. See figure “Cable dressing”.

  • Page 12: Service Modes, Error Codes, And Fault Finding

    Service Default Mode (SDM) 5.2.1 General Purpose Some items are applicable to all Service Modes or are general. This simplified SDM mode in LC8.1E LB chassis is used for These are listed below. Error blinking only. • Start the blinking LED procedure.
  • Page 13 Service Modes, Error Codes, and Fault Finding LC8.1E LB EN 13 button (do not allow the display to time out between entries 5. Clear. Erases the contents of the error buffer. Select the while keying the sequence). CLEAR menu item and press the MENU RIGHT key. The Note: content of the error buffer is cleared.
  • Page 14 5.3.1 ComPair Introduction 1 MODEL : 32PFL5403/12 ComPair (Computer Aided Repair) is a Service tool for Philips 2 PROD S/N : AG1A0831123456 3 SW ID : LC81EL1-1.0 WT - 1.4 Consumer Electronics products and offers the following: 4 OP : 3 2 0 255 8 0 1 1.
  • Page 15 ComPair II interface: 3122 785 91020. In case of non-intermittent faults, write down the errors present • The latest ComPair software can be found on the Philips in the error buffer and clear the error buffer before you begin Service website.
  • Page 16 EN 16 LC8.1E LB Service Modes, Error Codes, and Fault Finding Table 5-1 Error code overview Error code Description Item no. Remarks DC Protection of speakers 7C01 1) TV in protection mode 2) Red LED blinking 1 time (Error 1)
  • Page 17 Service Modes, Error Codes, and Fault Finding LC8.1E LB EN 17 Fault Finding and Repair Tips Notes: • It is assumed that the components are mounted correctly with correct values and no bad solder joints. • Before any fault finding actions, check if the correct options are set.
  • Page 18 EN 18 LC8.1E LB Service Modes, Error Codes, and Fault Finding AC ON 3V3STBY Available Weltrend Powered by 3V3_STBY, STANDBY=HIGH Power_ON_OFF=Low initialize GPIO pins of Weltrend Enable Audio mute STANDBY=Low Wait for 100ms Wait for 100ms Is Power Down Time out = 200ms...
  • Page 19 Service Modes, Error Codes, and Fault Finding LC8.1E LB EN 19 Start Mute Audio ANTI_PLOP=LOW MUTEn=HIGH BL_ON_OFF=LOW Wait 300ms Switch OFF LVDS Note: Total wait time 232ms iso 320ms Wait 20ms LCD_PWR_ON=LOW WP for NVM LOCTOP Enable Audio mute Port assignment in STANDBY...
  • Page 20 EN 20 LC8.1E LB Service Modes, Error Codes, and Fault Finding Start POWER_DOWN=LOW for 5 times ? Mute Audio & Video WP for NVM LOCTOP STANDBY=HIGH Wait 5000ms Re-start:Start up I_18170_037.eps 310708 Figure 5-8 Power Down flowchart...
  • Page 21 Service Modes, Error Codes, and Fault Finding LC8.1E LB EN 21 Start DC_PROT=Low for 3seconds? Mute Audio & Video WP for NVM STANDBY=HIGH I_18170_036.eps 310708 Figure 5-9 DC_PROT flowchart...
  • Page 22 EN 22 LC8.1E LB Service Modes, Error Codes, and Fault Finding Personal Notes: E_06532_012.eps 131004...

  • Page 23: Block Diagrams, Test Point Overview, And Waveforms

    Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB 6. Block Diagrams, Test Point Overview, and Waveforms Wiring Diagram 32" (MG8) WIRING 32" (STYLING MG8) LCD DISPLAY (1004) LVDS INPUT 8R50 INVERTER (1150) x418 14. PDIM_Select 13. PWM 12. BL_ON_OFF 11.

  • Page 24: Wiring Diagram 42" (Mg8)

    Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB Wiring Diagram 42" (MG8) WIRING 42" (STYLING MG8) LCD DISPLAY (1004) LVDS INPUT DANGEROUS DANGEROUS HIGH VOLTAGE HIGH VOLTAGE 8R50 (1150) MAIN POWER SUPPLY (1005) 1303 (B03) 9. POWER_ONOFF 8. +5V_SW 7.

  • Page 25: Block Diagram Video

    Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB Block Diagram Video VIDEO B05A SMIC L B04A TDA154XX B04C LVDS CONNECTORS TUNER IF & SAWF 7C01 7401 TDA15471HV TDA8890H1 1104 1102 UV1316E VIF1 1R50 MAIN VIF2 TUNER VDISP SAW 38M9...

  • Page 26: Block Diagram Audio

    Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB Block Diagram Audio AUDIO B05A B04A B05B TUNER IF & SAWF SMIC L TDA154XX AUDIO CLASS D 7401 7C01 TDA8890H1 TDA15471HV 1104 1102 UV1316E VIF1 7A01 TDA8932T/N1 MAIN VIF2 TUNER SAW 38M9...

  • Page 27: Block Diagram Control & Clock Signals

    Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB Block Diagram Control & Clock Signals CONTROL & CLOCK SIGNALS KEYBOARD CONTROL MICROPROCESSOR NVM B04A TDA154XX 7C01 TDA15471HV POWER_ONOFF_LOCTOP 1C01 KEYB TxCLKp REMOTE B04C LOC TOP TxCLKn IR LED PANEL B04C...

  • Page 28: Ssb: Test Points (Overview Bottom Side)

    Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB SSB: Test Points (Overview Bottom Side) A115 C1 F710 C4 I105 IA50 F1 A116 C1 F711 C3 I106 IA51 F1 A124 C1 F712 C3 I108 IA52 F1 A125 C1 FA01 F3...
  • Page 29 Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB SSB: Test Points (Part 1 Bottom Side) Part 1 I_18170_014a.eps 210708...
  • Page 30 Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB SSB: Test Points (Part 2 Bottom Side) Part 2 I_18170_014b.eps 310708...

  • Page 31: I2C Ic Overview

    Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB I2C IC Overview I²C MICROPROCESSOR NVM B04A TDA154XX TUNER IF & SAWF B05A SMIC L B06C SCART2 & UART & JTAG 7303 +3V3_STBY WT61P8S IIC_SDA IIC_SDA DS1-DA IIC_SCL IIC_SCL DS1-CL MICRO...

  • Page 32: Supply Lines Overview

    Block Diagrams, Test Point Overview, and Waveforms LC8.1E LB Supply Lines Overview SUPPLY LINES OVERVIEW DC / DC +5V & +3V3 & +2V5 +1V8 & +1V2 B05B AUDIO - CLASS D +12V_AUDIO +12V_AUDIO VDDA TUNER IF & SAWF +12V 5A05...

  • Page 33: Circuit Diagrams And Pwb Layouts

    Circuit Diagrams and PWB Layouts LC8.1E LB 7. Circuit Diagrams and PWB Layouts SSB: DC/DC 1P01 A12 7P04 F8 1P02 B11 7P05 A3 DC/DC +5V & +3V3 & +2V5 & +1V8 & +8V 2P01 F7 7P06-1 B4 2P02 F7 7P06-2 C4...

  • Page 34: Ssb: Tuner If & Sawf

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: Tuner IF & SAWF 1102 A7 1103 C7 TUNER IF & SAWF 1104 E1 2101 H3 2102 H3 2103 G5 2104 G5 2105 G6 2106 F7 2109 H11 2110 H11 2111 G4...

  • Page 35: Ssb: Micro Processor Nvm (B03)

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: Micro Processor NVM 1301 G4 F306 E3 MICROPROCESSOR NVM 1302 C13 F307 F3 1303 I2 F308 J3 1304 I4 F309 J4 1306 I5 F310 J4 1307 J3 F311 J4 1308 J3 F313 J3...

  • Page 36: Ssb: Tda154Xx (B04A)

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: TDA154XX 1C01 G16 3C58-2 B12 1C02 H12 3C58-3 B12 1C03 G1 3C58-4 B12 TDA154XX 2C01 H16 3C59-1 B12 B04A B04A 2C02 G15 3C59-2 B12 2C03 G15 3C59-3 B12 2C04 E6 3C59-4 B12...

  • Page 37: Ssb: Ddr Flash Trap

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: DDR Flash Trap 1701 B9 DDR FLASH TRAP 2701 B2 B04B B04B 2702 B3 2703 B3 2704 B3 +3V3_SW 2705 D2 2706 D2 2707 F3 2709 B4 2710 B4 3708 3709 3710...

  • Page 38: Ssb: Lvds Connectors

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: LVDS Connectors 1R10 B2 LVDS CONNECTORS 1R11 B2 B04C B04C 1R12 C2 1R13 D2 1R14 D2 1R50 B6 2R01 B9 2R02 B9 2R03 C8 5R01 3R02 C7 IR04 7R02 3R13 C7 220R...

  • Page 39: Ssb: Smic L (B05A)

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: SMIC L 2401 E10 I416 D8 2402 D9 I417 B7 SMIC L B05A 2403 C10 I418 C5 B05A 2404 C11 I419 C5 2405 C11 I420 C5 2406 C11 I421 D5 2407 D10...

  • Page 40: Ssb: Audio Class D

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: Audio Class D 1A35 D15 2A05 E12 2A12 D8 2A18 D10 2A23 D12 2A29 E8 2A34 F10 2A45 D12 2A64 A13 3A01 A5 3A06 D7 3A11 D7 3A16 G13 3A21 D7 3A28 F13...

  • Page 41: Ssb: Ypbpr & Svhs (B06A)

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: YPBPR & SVHS 1601 B6 6604 B7 YPBPR & SVHS B06A B06A 1602-1 C6 6606 C7 1602-2 D6 6610 E2 1602-3 C6 6611 D2 1605 1603 F5 6612 F2 SIDE_AUDIO_IN_L 1605 A6...

  • Page 42: Ssb: Io Scart 1

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: IO Scart 1 1501 C10 IO - SCART 1 1504 A2 B06B B06B 1505 A3 SC1_AUDIO_MUTE_R 1506 B3 3503 F534 SC1_AUDIO_OUT_R 1507 B3 1508 F3 150R 2508 1509 G3 330p 1511 C3...

  • Page 43: Ssb: Scart2 & Uart & Jtag

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: Scart2 & UART & JTAG 1E01 A1 FE27 E4 SCART2 & UART & JTAG 1E03 B8 FE28 F5 B06C B06C 1E04 C6 FE29 G5 JTAG INTERFACE RESERVED 1E05 B8 FE30 C4 1E08 B8...

  • Page 44: Ssb: Hdmi

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: HDMI 1N01 E3 1N02 H3 HDMI 2N01 B13 B06D B06D 2N02 B8 2N03 B13 2N04 E17 2N05 C14 2N06 B9 2N07 B10 2N10 G17 2N17 B14 2N18 B14 IN15 5N03 FN03 2N19 B14...

  • Page 45: Ssb: Srp List Explanation

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: SRP List Explanation Example Personal Notes: 1 . 1 . Introduction Net Name Diagram +12-15V AP1 (4x) +12-15V AP4 (4x) SRP (Service Re ference Protocol) is a softw are too l that creates a list w i th all refer e n c es to signal lines. The list contains...

  • Page 46: Ssb: Srp List

    Circuit Diagrams and PWB Layouts LC8.1E LB SSB: SRP List Netname Schematic GND60 B04A (2x) MAIN_CVBS_Y B04A (1x) SC1_FBL_IN B06B (2x) B05B (3x) GND78 B04A (2x) MAIN_CVBS_Y B05A (1x) SC1_G_IN B05A (2x) VSSA B05B (5x) GND86 B04A (2x) MAIN_L B04A (1x)
  • Page 47 Circuit Diagrams and PWB Layouts LC8.1E LB Layout Small Signal Board (Overview Top Side) 1102 C4 2316 A3 2623 C4 2C28 C3 2P01 A1 3325 B3 3434 D4 3A30 F2 3E14 D4 3P32 E1 5C07 C3 7304 C2 1103 C4...
  • Page 48 Circuit Diagrams and PWB Layouts LC8.1E LB Layout Small Signal Board (Part 1 Top Side) Part 1 I_18170_013a.eps 170708...
  • Page 49 Circuit Diagrams and PWB Layouts LC8.1E LB Layout Small Signal Board (Part 2 Top Side) Part 2 I_18170_013b.eps 170708...
  • Page 50 Circuit Diagrams and PWB Layouts LC8.1E LB Layout Small Signal Board (Part 3 Top Side) Part 3 I_18170_013c.eps 170708...
  • Page 51 Circuit Diagrams and PWB Layouts LC8.1E LB Layout Small Signal Board (Part 4 Top Side) Part 4 I_18170_013d.eps 170708...

  • Page 52: Keyboard Control Panel

    Circuit Diagrams and PWB Layouts LC8.1E LB Keyboard Control Panel Layout Keyboard Control Panel (Top Side) 1N10 A1 1N13 C3 1N16 C4 3N08 B1 3N12 B3 3N15 B4 6N10 B2 FN11 B1 IN12 B3 IN15 B4 1N11 C2 1N14 C4...
  • Page 53 Circuit Diagrams and PWB Layouts LC8.1E LB IR & LED Panel 1P09 A1 IR & LED PANEL 1P10 B1 1P11 C1 "RED" "WHITE" 2P10 E5 TO ME8 LIGHT GUIDE 2P11 E5 +5V_SW 1P09 +3V3STBY 2P12 E6 +3V3STBY 2P13 E6 3P07 C3...

  • Page 54: Ir & Led Panel

    Circuit Diagrams and PWB Layouts LC8.1E LB Layout IR & LED Panel (Top Side) Personal Notes: 2P10 A4 3P09 A6 3P13 A6 3P17 A5 3P21 A6 3P25 A6 4P01 A2 6P12 A5 7P13 A6 2P11 A6 3P10 A3 3P14 A2...

  • Page 55: Alignments

    (use multimeter and RF generator): Perform all electrical adjustments under the following • Apply a 70 dB (1mv) RF signal with a Philips standard conditions: circuit pattern to antenna input. • Power supply voltage (depends on region): •...
  • Page 56 EN 56 LC8.1E LB Alignments Table 8-3 Tint settings 32" digital diagnosis possible, the microprocessor has to know which ICs to address. The presence/absence of these specific ICs (or functions) is made known by the option codes. Colour Temp. Cool...
  • Page 57 Alignments LC8.1E LB EN 57 Table 8-6 Option codes at bit level (OP1-OP7) Option Byte & Bit Dec. Value Option Name Description Byte OP1 Bit 7 (MSB) OPC_BBE ON = BBE is available OFF = BBE is not available Bit 6...

  • Page 58: Circuit Descriptions, Abbreviation List, And Ic Data Sheets

    Introduction Index of this chapter: 9.1 Introduction 9.2 LCD Power Supply The LC8.1E LB chassis (development name “LC08EE”) is a 9.3 DC/DC converters new chassis using an NXP “LOC-TOP” chipset. It covers 9.4 Front-End screen sizes of 32" and 42" with the “MG8” styling.
  • Page 59 Circuit Descriptions, Abbreviation List, and IC Data Sheets LC8.1E LB EN 59 9.1.1 SSB Cell Layout DC - DC CONVERSION TUNER ANALOGUE I/O STANDBY TDA1547 CONTROLLER TDA8890 SMIC DC - DC CONVERSION ANALOGUE I/O AUDIO CLASS - D I_18170_039.eps 310708...
  • Page 60 EN 60 LC8.1E LB Circuit Descriptions, Abbreviation List, and IC Data Sheets TO INVERTER (Right) TO PANEL Left Right X402 X403 Pin11 -12V (audio) GND2 (audio) Pin14 +12V (audio) PDIM_Select +12V On/Off +12V Vbri X416 GND3 +12V GND3 Pin1 GND1...
  • Page 61 Circuit Descriptions, Abbreviation List, and IC Data Sheets LC8.1E LB EN 61 • Switchable group delay correction and sound trap (with switchable centre frequency) for the demodulated CVBS Tuner IF Diagram signal • Separate SIF (Sound IF) input for single reference QSS...
  • Page 62 EN 62 LC8.1E LB Circuit Descriptions, Abbreviation List, and IC Data Sheets DC-protection A DC-detection circuit is foreseen to protect the speakers. It is SAW-SW built around three transistors (items 7A05 to 7A07) and Tuner 1104 SIFIN1,SIFIN 267,68 SIF1,2 generates a protection signal (DC_PROT) to the...

  • Page 63: Abbreviation List

    Circuit Descriptions, Abbreviation List, and IC Data Sheets LC8.1E LB EN 63 BTSC Broadcast Television System Committee Conditional Access Module Circuit Board Assembly (or PWB) Consumer Electronics Control bus; remote control bus on HDMI connections Common Interface; E.g PCMCIA slot...
  • Page 64 SCART output of the MSP audio IC LATAM LATin AMerica SC2-OUT SCART output of the MSP audio IC LC08 Philips chassis name for LCD TV 2008 Short Circuit project Clock signal on I2C bus Liquid Crystal Display Standard Definition: 480i, 576i...

  • Page 65: Ic Data Sheets

    Circuit Descriptions, Abbreviation List, and IC Data Sheets LC8.1E LB EN 65 IC Data Sheets This section shows the internal block diagrams and pin layouts of ICs that are drawn as "black boxes" in the electrical diagrams (with the exception of "memory" and "logic" ICs).
  • Page 66 EN 66 LC8.1E LB Circuit Descriptions, Abbreviation List, and IC Data Sheets 9.8.2 Diagram B03, Type WT61P8S (IC7303), Weltrend Microprocessor Block Diagram Turbo 8052 MCU 32K bytes Slave IIC code flash Internal 256 VGA DDC bytes SRAM Timer0, DVI DDC...
  • Page 67 Circuit Descriptions, Abbreviation List, and IC Data Sheets LC8.1E LB EN 67 9.8.3 Diagram B04A, Type TDA15471HV (IC7C01), LOC-TOP Video/Audio Processor Block Diagram Pin Configuration I_18170_025.eps 290708 Figure 9-17 Internal block diagram and pin configuration...
  • Page 68 EN 68 LC8.1E LB Circuit Descriptions, Abbreviation List, and IC Data Sheets 9.8.4 Diagram B05A, Type TDA8890H1 (IC7401), Versatile Front-End Signal Processor Block Diagram SCART/CINCH IN/OUT 5/8V SSIFOUT SWITCH MAINOUTL/R QSS SOUND IF AUDIO SELECT SIFIN AGC2SIF DSPINL/R QSS MIXER...
  • Page 69 Circuit Descriptions, Abbreviation List, and IC Data Sheets LC8.1E LB EN 69 9.8.5 Diagram B05B, Type TDA8932BT (IC7A01), Audio Amplifier Block Diagram BOOT1 OSCILLATOR DDP1 IN1P DRIVER HIGH OUT1 CTRL MODULATOR DRIVER SSP1 IN1N MANAGER BOOT2 INREF DDP2 IN2P DRIVER...
  • Page 70 EN 70 LC8.1E LB Circuit Descriptions, Abbreviation List, and IC Data Sheets 9.8.6 Diagram B06D, Type IP4776 (IC7N07), HDMI Interface Block Diagram TMDS_BIAS TMDS_CLK+ CC(5V0) TMDS_D2− TMDS_D1− TMDS_GND TMDS_D0− TMDS_CLK− TMDS_BIAS TMDS_BIAS CC(3V3) CC(3V3) DDC_CLK_IN DDC_CLK_OUT CEC_IN CEC_OUT TMDS_BIAS TMDS_BIAS...

  • Page 71: Spare Parts List & Ctn Overview

    Spare Parts List & CTN Overview LC8.1E LB EN 71 10. Spare Parts List & CTN Overview For the latest spare part overview, please consult the Philips Service website. Table 10-1 Sets described in this manual: Styling Published in: 32PFL3403/12...
