LAUNCH
2.3 Power Source
The product does not have an independent power supply, you can power it up
via either of the followings ways:
• Use the included power adaptor
• Connect the device through the vehicle's DLC

2.4 Accessories

4
Accessory Name
Main Diagnostic
Cable
Power adaptor
The fourth-
generation data
acquisition cable
The fourth
generation of
EEPROM data
acquisition
cable (without
dismantling
dashboard)
X-PROG 3 User Manual
Descrption
To connect vehicle DLC port,
VCI and programmer for
diagnose.
To provide power supply for
the programmer.
After removing the vehicle
dashboard, connect
programmer, vehicle
dashboard, and the cable.
Connect the programmer and
vehicle dashboard,and then
place the probe(the yellow
lead) to the designated area.
