INSTRUCTION MANUAL
Item No. 20999 3 Burner Gas Grill

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 20999 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MaxxGarden 20999

Summary of Contents for MaxxGarden 20999

  • Page 1 INSTRUCTION MANUAL Item No. 20999 3 Burner Gas Grill...
  • Page 2 3 Burner Gas Grill...
  • Page 3 SAFETY INSTRUCTIONS 1. Read the instruction manual carefully before use and keep it for future reference. Failure to comply with the instructions can result in death, serious injury or property damage. 2. For outdoor use ONLY! Do not use indoors. 3.
  • Page 4 PART LIST Pic. Pic. Top door M5*12 screw M4*6 screw...
  • Page 5 Assembly Note: Please do not tight the screws and nuts till all assembly steps completed. 1. Assemble the LH and RH frame (5&6) to bottom shelf (7) with 4pcs M5 screws (B).
  • Page 6 Assembly 2. Assemble the back shelf (9) to the frames with 4 pcs M5 screws (B).
  • Page 7 Assembly 3. Assemble the front beam (8) to the front of frames with 4pcs M5 screws (B).
  • Page 8 Assembly 4. Assemble the 4pcs wheels (10&11) to the end of frame legs. Note: the 2pcs wheels with break (10) are always in the same side.
  • Page 9 Assembly 5. The body (1) is slided into the frame legs with 8 pcs pre-assembled M5 screws (See detailed pic.). Tight screws after body slided into position. Note: make sure the 8pcs screws are pre-assembled before sliding.
  • Page 10 Assembly 6. LH side shelf (14) is asssembled to the body with 6 pcs M5 screws (B).
  • Page 11 Assembly 7. RH side shelf (15) is asssembled to the body with 6 pcs M5 screws (B).
  • Page 12 Assembly 8. Handles (13) are assembled to front doors (12) with 4pcs M4 screws (C). Totally 2 pcs doors.
  • Page 13 Assembly 9. Doors are assembled to frames’ front legs with 2pcs top door pins (A).
  • Page 14 Assembly 10. Warming grid (2), cooking grids (3) and heat tents (4) are fixed into the body.
  • Page 15 Assembly 11. Oil cup (16) is assembled to the oil pan. Tight all screws before use Assembly completed...
