Fig. 1 AQA therm HFB-1717 BA
1
2
1
8
Abb. 3 AQA therm HFB-1717 BA &
AQA therm HES
14
6280_EBA AQA therm HFB_HES_HWG_313660-5.indd 14
5
6
9
3
4
Optional:
AQA therm HRC
(softening)
or
AQA therm SRC
(desalination)
Fig. 2 AQA therm HES
1 Ball valve
2 Pressure gauge
3 Pressure reducer with removable
adjustment handle
4 Optional: AQA therm HRC or SRC
5 Water meter with smart operation display
6 Bleed valve / distilled water-filling point
8 Drain valve with pipe connection
9 Shut-off ball valve
24.09.15 09:09
