Blodgett SC-10E Specifications

SC-E
Electric Convection Steamer
on a 24" Modular Cabinet Base
SC-7E shown
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage options
220 VAC, 3 phase, 60 hz
240 VAC, 3 phase, 60 hz
220/380, 3 phase, 60 hz, 4 wire
240/415, 3 phase, 60 hz, 4 wire
380 VAC, 3 phase 60 hz
415 VAC, 3 phase, 60 hz
480 VAC, 3 phase, 60 hz
600 VAC, 3 phase, 60 hz
12" x 20" (305 x 508 mm) pan guides for cabinet base
120 minute timer
Correctional package
One year extended warranty
CAPACITY
Model SC-7E is comprised of one 3 pan steamer com-
partment and one 4 pan steamer compartment
Model SC-10E is comprised of two 5 pan steamer com-
partments
Model
1" 2.5"
SC-7E 14
SC-10E 20
Pan Depth
4" 6"
7 4 2
10 6 4
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Project
Item No.
Quantity
Model SC-7E (7 pan electric convection steamer)
Model SC-10E (10 pan electric convection steamer)
EXTERIOR CONSTRUCTION
304 satin finish stainless steel
Welded stainless steel door with removable inner stainless steel liner
Full perimeter door gasket
Positive lock and seam mechanism with spring release on door
Stainless steel control housing
INTERIOR CONSTRUCTION
One piece welded 316 stainless steel cooking chamber
Coved corners
Stainless steel pan supports
Stainless steel drip trough integrally connected to drain
OPERATION
Pressureless steam operation
Delime mode power setting
Automatic generator blowdown
Separate controls for each compartment
Full access removable control panel
Illuminated on/off/delime power switch
Ready indicator light
Cooking indicator light
60 minute electric timer with audible alarm to signal end of cook cycle
Solid state generator controls
Steam flow to the cooking chamber is cut off when the door is opened
during the cooking cycle and reactivated when the door is closed
STANDARD FEATURES
Deliming port located in the rear of the unit for each generator
Deliming mode power setting
Electromechanical controlsl
Split water connections
24" wide cabinet base with hinged door and 6" (152 mm) legs
Standard voltage options
208 VAC, 3 phase, 60 hz
240 VAC, 3 phase, 60 hz
One year parts and labor steamer warranty*
Five year limited steamer door warranty*
* For all international markets, contact your local distributor.
BLODGETT
