mectron OzoActive Assembly

Assembly prophylaxis device / ozoactive

→ MECTRON

→

ASSEMBLY PROPHYLAXIS DEVICE / O ZOACTIVE

OZOACTIVE

Connect foot-pedal via the jack terminal

OZOACTIVE

OzoActive produces ozone

and injects it directly into

mectron device irrigation

lines, providing ozonated

water which reduces the

risk of fungi, bacteria and

virus contamination through

aerosols. The OzoActive

(*)

device is compatible with

the COMBI touch and the

Multipiezo device line.

OZOACTIVE

Connect the power cord

Table of Contents

Need help?

Do you have a question about the OzoActive and is the answer not in the manual?

Page 1 → MECTRON OZOACTIVE → ASSEMBLY PROPHYLAXIS DEVICE / O ZOACTIVE OzoActive produces ozone and injects it directly into mectron device irrigation lines, providing ozonated water which reduces the risk of fungi, bacteria and virus contamination through aerosols. The OzoActive...
Page 2 → MECTRON OZOACTIVE OZOACTIVE MECTRON DEVICE Connect the thinner tube of the Disconnect the foot-pedal cable Prophylaxis irrigation kit into the designated coupler MECTRON DEVICE MECTRON DEVICE Connect foot-pedal via the Remove the cover of the peristaltic Ethernet plug port pump motor...
Page 3 Looking at the rotating pump, disconnect Connect the hose to the coupler on the tube on the left and connect it to the the mectron device tube-tube connection of the irrigation kit NOTE: Arrow indicates the direction of water flow (*)
Page 4 See indications table WARNING • COMBI touch: OzoActive is usable only with bottle irrigation (ultrasound ablation only). Select bottle irrigation function. Default level of irrigation is 3. Utilize + and - buttons to adjust the level of irrigation.
