Coxo C-SMART-I+ User Manual page 6

4. Deciding the working length of root canal when the figure on the LCD
screen shows 0.5mm, then measure the distance from the bottom of
rubber vernier caliper to the tip of the file. Take note of this figure.
So subtract 0.5-1.0mm from the above data is the working length of
root-canal.
When the file drills through the root-canal,please make the final value
in terms of the one measured in 0.5mm.
The working length of root-canal varies from each other for the reason
of different shapes of teeth and root-canal.
5. When the file reaches the position to 2.0mm away from the apex of the
root-canal, there will be a continuous alarm.
In M2 Mode, you can assemble the unit as follow:
M2: Single root canal expanded function, hold down the foot switch or
press the handle button, the file will rotate; when the file arrived at
the setting torque, the file will automatically reverse. When the
torque reduces, the file will recover forward. Loosen the foot switch
or press the handle button, the file stops rotating.
嘟
9
AUTO1
AUTO1
AUTO1
The calibration function:
AUTO1
Under the mode of M2, the program is set to 1, and then set the rate of
125, torsion as 52, and then press "-" key about 3 seconds long, hear
ringing sound for four, namely into the calibration mode. In calibration
mode, the motor rotating, buzzer will ring a sound every 16 seconds, the
entire process for a minute and a half. After that, the unit continuous ring
4 times.
Notice:
This function is only applicable to replacing contra angle or motor , uses
for calibration parameters to support new equipment. Before entering the
calibration model, it should connect the motor and contra angle , plug in
the file, and place the motor. In the process of calibration, don't touch
the contra angle and the file, to avoid causing the calibration error. After
calibration is completed, the user must be shutdown, restart again.
踩 按
AUTO1
10
