Function Definition - Coxo C-SMART-I+ User Manual

1. Put the instrument on a solid place.
2. Connect the plug of the motor wire to the main unit, make sure that
they are in the right position.
3. Connect the contra angle to the motor.
4. Put the well connected main unit on the handle holder reposefully.
5. Insert the foot switch plug into the jack on the main unit in M2 and M3.
6. In M1,Insert the test wire to the hole on the main unit, and connect the
file holder to test wire.
7. In M4 ,connect the
lip hook line
Notice:
Please wear rubber gloves when operation.

Function definition

Key and display
1 2
4
1 POWER key
REVERSE key
2
3 PROGRAM key
MODE key
4
to
the end of the handle socket.
3 6
5 7
5
SET key
6 UP key
7 DOWN key
5
AUTO1
a
b
a Mode area
Direction area
b
c Apex locator area
Speed area
d
1
. Power
Press power key to turn on the unit, information will be displayed on
1
LCD; press it again to turn off unit, information which on the LCD will
disappears.
2. Direction switch
Press reverse key 2 to set the working direction of the file, icon will be displayed
on direction area b .
Direction display:
Forward.
3.Program switch
Press program key 3 can switch the program, there are 9 programs can be saved;
rogram area
and which displayed on p
4.Mode switch
Press mode key can switch the mode, there are 4 modes can be select; and
4
a
which displayed on mode area .
5.Setting and adjust
Press set key 5 can switch between speed area
g
area , the value of the area which being selected will blink, and press the up
key 6 and down key 7 to adjust the value.
h
d
e
f
g
c
Torque area
e
Current torque indicator
f
g
Program area
Battery level area
h
Reverse.
g
.
, torque area and program
d e
6
