HYDRAULICALLY POWERED WINCHES
w w w . s u p e r w i n c h . c o m
Superwinch LTD.
Union Mine Road, Pitts Cleave
Tavistock, Devon. PL19 0PW
Tel:
+44 (0) 1822 614101
Fax: +44 (0) 1822 615204
E-mail: sales@superwinch.net
Owners Manual 5-201-001 Issue 1
OWNER'S MANUAL
H8P-PRO / H10P-PRO
EN 14492-1
EN 14492-1
Superwinch LLC.
Winch Drive, Putnam
Connecticut 06260 U.S.A.
Tel:
01 800 323 2031
Fax: 01 860 963 0811
E-mail: info@superwinch.com
Page
1
Winch shown for
illustration purposes only
Advertisement
Related Manuals for Superwinch H8P-PRO
Summary of Contents for Superwinch H8P-PRO
- Page 1 OWNER’S MANUAL H8P-PRO / H10P-PRO EN 14492-1 EN 14492-1 HYDRAULICALLY POWERED WINCHES w w w . s u p e r w i n c h . c o m Winch shown for illustration purposes only Superwinch LTD. Superwinch LLC.
- Page 2 WINCH CABLE MAINTENANCE AND USE FREESPOOL USE RUNNING IN, MAINTENANCE & SERVICING TIPS FOR EXTENDING THE LIFE OF YOUR WINCH SPARES & ACCESSORIES WARRANTY NOTES For all your requirements please contact your Superwinch agent Owners Manual 5-201-001 Issue 1 Page...
- Page 3 INTRODUCTION Thank you for purchasing a Superwinch Pro. It has REPAIRS AND REPLACEMENTS been designed and manufactured to meet BS EN 14492-1, Power Driven Winches Standard, and provide years of Before you contact Superwinch or your nearest Dealer please trouble-free operation.
-
Page 4: Specification Data
Manual Manual To ensure that winches are compliant with the European standard, BS-EN14492-1 Superwinch recommends that wire ropes should be as follows: 10mm dia for H8P winch with a tensile grade of 1960 and a min break figure of 7,119kg (69.8kN) 11mm dia for H10P winch with a tensile grade of 1960 and a min break figure of 8,608kg (84.4kN) -
Page 5: Winch Installation
Superwinch flatbed mounting kit (Part No. 5625), Pressure hoses: 13mm (1/2”) N.B. shown with Roller Fairlead. If a Superwinch mounting plate is not (control valve to load control valve) used, the surface must be flat within 0.5 mm and sufficiently stiff to prevent flexing. - Page 6 WINCH INSTALLATION VERSION H8P - 190mm DRUM LENGTH 207.0mm 190.0mm 602.0mm 228.5mm 298.5mm 311.0mm H8P - 253mm DRUM LENGTH 207.0mm 253.0mm 665.0mm 291.5mm 361.5mm 374.0mm H10P -190mm DRUM LENGTH 214.0mm 190.0mm 609.0mm 228.5mm 298.5mm 311.0mm H10P - 253mm DRUM LENGTH 207.0mm 253.0mm 665.0mm...
- Page 7 Check the winch for operation in both directions. 1. To dis-engage the freespool (if engaged) pull the knob and turn 90° ensuring that the knob stays out. 3. Repairs should be carried out by authorised Superwinch repair centres only. Do not attempt disassembly of the gearbox.
- Page 8 MAINTENANCE & USE TIPS FOR EXTENDING THE LIFE OF YOUR WINCH Ensure Roll Pins in Clutch Housing Cover (Item 5), align holes in clutch plate. 1. Note: Installing the wire rope is not included in the running-in 7. Replace gasket, Item 1, and Clutch Cover Assembly. period.
-
Page 9: Spares And Accessories
SPARES & ACCESSORIES H8P / H10P SERIES WINCHES, GENERAL ASSEMBLY, WITH LOAD CONTROL VALVE Item Description Part No. Qty. Cap Hd Screw 4-36-0603022 Spring Washer 4-51-0623 Cap Hd Screw 4-36-0601022 Screw Seal 4-23-063 Roll Pin 4-56-802003 Spring 4-31-1403030403 Brake Housing 50-90622-01 Brake Housing, (5052Gg, only) 50-25160... -
Page 10: Optional Accessories
OPTIONAL ACCESSORIES Optional accessories, designed by Superwinch exclusively for the H8 and H10P: Roller Fairlead Part No. 5600 Standard Drum 190 mm Drum Length Roller Fairlead Part No. 5610 Long Drum 253 mm Drum Length Rope Drum Safety Guard Part No. 50-30171, Standard Drum Cable Tensioner Part No. - Page 11 A. Express Warranties. Seller warrants that the Superwinch is as described in the “Superwinch Owner’s Manual” provided herein; no other express warranty is made in respect to the Superwinch. If any model or sample was shown to the buyer, such model or sample was used for illustrative purposes only, and shall not be constructed as a warranty that the Superwinch will conform to the sample or model.
- Page 12 NOTES Owners Manual 5-201-001 Issue 1 Page...
