  • Page 1 Assembly Instructions FOLDING BARBECUE...

  • Page 2: Overview

    Overview...

  • Page 3: Scope Of Delivery/Product Components

    Scope of delivery/product components Scope of delivery/product components Please check parts against the list below assembling your Barbecue Grill. Take a few moments to familiarise yourself with the contents. Check that all holes are clear of paint before assembly. Base (×1) Charcoal Tray (×1) Cooking Grid (×1) Locking Pins (×2)

  • Page 4: Table Of Contents

    Table of content Table of content Overview........................2 Scope of delivery/product components..............3 General information....................5 Reading and storing the assembly instructions............5 Intended use........................5 Explanation of symbols.....................5 Safety........................6 Safety notes........................6 Assembly instruction....................8 Step 1: Open the base......................9 Step 2: Lock side parts.......................

  • Page 5: General Information

    General information General information Reading and storing the assembly instructions These assembly instructions are a part of the Folding Barbecue (hereinafter simply called "product"). They contain important information about assembly and use. Read the assembly instructions carefully, in particular the safety instructions, before using the product.

  • Page 6: Safety

    Safety Safety WARNING! Do not use the barbecue in a confined and/or habitable space e.g. houses, tents, caravans, motor homes, boats. Danger of carbon monoxide poisoning fatality. The following signal words are used in these assembly instructions. This signal symbol/word denotes a hazard with WARNING! an average risk level that could lead to death or severe injury if it is not avoided.
  • Page 7 Safety Never dump hot charcoal or ashes where it might be stepped on or be a fire hazard. Never dump ashes or charcoal before they are fully extinguished. Allow the barbecue to cool down completely before cleaning it. During use, the screw connections can loosen and adversely affect the stability of the barbecue.

  • Page 8: Assembly Instruction

    Safety The maximum depth of charcoal for this barbecue is approx 5 cm (see technical data), the minimum amount approx 3 cm. Do not cook before the charcoal has a coating of ash. Assembly instruction CAUTION! Risk of injury! Some parts of the barbecue might have sharp edges. Touching these parts can cause cuts.

  • Page 9: Step 1: Open The Base

    Assembly instruction Step 1: Open the base Push both locking pins on outside of the base and open the base Base is unfolded. Step 2: Lock side parts Turn both side parts of the base outwards and secure the side parts with the clamps Side parts are secured.

  • Page 10: Step 4: Secure The Charcoal Tray

    Assembly instruction Step 4: Secure the charcoal tray Move the charcoal tray into base Pay attention that the two locking plates grip into the holes of the base The charcoal tray is secured. Step 5: Assemble the cooking grid Unfold the cooking grid .

  • Page 11: Use

    WARNING! Risk of burns This barbecue will become very hot! Touching may cause burn injuries. - Use heat-resistant barbecue mitts or gloves (conforming to EN 407, Contact Heat rating level 2 or greater) while cooking, adjusting air vents (dampers), adding charcoal, and handling thermometer or lid.

  • Page 12: The First Time You Grill

    The first time you grill Before first use clean all parts to come into contact with foodstuffs especially the cooking grid , according to chapter “Cleaning”. 2. It is recommended that the barbecue be heated up and the charcoal kept red hot for at least 30 minutes prior to cooking for the first time.

  • Page 13: Cleaning

    adjusting air vents (dampers), adding charcoal, and handling thermometer or lid. - Do not place lighter cubes on the embers or the refilled charcoal. Place the cooking grid on a heat resistant surface. Keep others away from the hot cooking grid! 2.

  • Page 14: Storage

    3. For easy storage fold Base and slide in parts according to picture 7. 4. Store the barbecue at a dry place protected from the elements. Technical data Model: FB-001 Dimensions (W × D × H): 47 × 43 × 4 cm...

  • Page 15: Disposal

    Technical data Weight: approx. 4 kg Fuel: Charcoal Max. fuel capacity: 0.6 kg Item number 702089 Disposal Disposing of packaging Dispose of packaging according to type. Sort the paperboard and cardboard as waste paper and the film as recyclable material. Product disposal Dispose of the product in line with the guidelines and disposal regulations applicable in your country.
  • Page 16 ALDI STORES LTD. PO BOX 26, ATHERSTONE WARWICKSHIRE, CV9 2SH. ALDI STORES (IRELAND) LTD. PO BOX 726, NAAS, CO. KILDARE. Visit us at www.aldi.com AFTER SALES SUPPORT 702089 0121 36 80 339 01 50 60 684 www.bestbuyingsupport.com YEAR MODEL: WARRANTY FB-001 06/2020...
