Autostart AS705S V1.00 – V1.06(a)
Autostart AS710S/AS720S/AS730S V1.00 – V1.09(a)
PC Communication and Software (AS7CK V1.07)
Please read the following information before installing. A visual inspection of this product for damage during
shipping is recommended before installation. It is your responsibility to ensure that qualified mechanical and electrical
technicians install this product. If in doubt, please contact your local Murphy representative.
1
INTRODUCTION
All Autostart AS705S, AS710S and AS730S controls fitted with
firmware versions V1.0 or higher have a serial communication
port, accessed through a 9 way D-connector at the unit's rear.
This port, when used with other hardware accessories, may be
used to set up a communication link between an Autostart and a
PC running Murphy software model AS7CK. This software may
then be used for the monitoring, control and programming of any
Autostart in the range.
The information in this document is current for:-
• AS705S units with firmware V1.00 – V1.06(a)
• AS710S and AS730S units with firmware V1.00 – V1.09(a)
• (obsolete) AS720S units with firmware V1.00 – V1.05
• AS7CK software version V1.07
Firmware and software versions before or after these revisions
may contain more, less or reconfigured features. If in doubt,
please contact our technical sales department for up to date
product information and compatibility details.
Further details on specification, installation and operation of the
Autostart range can be found in the following documents:-
Doc. ref.
Title
ms5258
AS705S bulletin
mi5396
AS705S installation and wiring
ms5259
AS710S bulletin
mi5262
AS710S installation and wiring
ms5261
AS730S bulletin
mi5264
AS730S installation and wiring
mi5265
AS7xx installation section B: programming
The above are available on request from your Murphy
representative, or from the 'products' section of our website
www.fwmurphy.co.uk
FW Murphy
PO Box 470248
Tulsa, Oklahoma 74147, USA
tel: +1 918 317 4100
fax: +1 918 317 4266
email: sales@fwmurphy.com
web: www.fwmurphy.com
In order to consistently bring you the highest quality, full featured products, we reserve the right to change our specifications and designs at any time.
CONTROL SYSTEMS AND SERVICES DIVISION
PO Box 1819, Rosenberg, Texas 77471, USA
tel: +1 281 633 4500
fax: +1 281 633 4588
email: sales@fwmurphy.com
MURPHY DE MEXICO S.A. DE C.V.
Blvd. Antonio Rocha Cordero 300, Fracción del Aguaje
San Luis Potosí, S.L.P. México 78384
tel: +52 444 8206264
fax: +52 444 8206336
Villahermosa office tel: +52 993 3162117
email: ventasmex@murphymex.com.mx
web: www.murphymex.com.mx
2
HARDWARE
2.1 Hardware Accessories
Several standard communication components are available,
combinations of which allow the link to be 'local' (an RS232 link of
less than 10 metres) or 'remote' (by use of RS232 modems and the
telephone network):-
Model No. Description
AS7CA
9 way to 9 way serial (null modem) lead, for local
communication where the PC has a 9 way COM port.
AS7CB
9 way to 25 way serial (null modem) lead, for local
communication where the PC has a 25 way COM port.
AS7CC
RS232 interface unit for local communication only
AS7CD
RS232 interface unit for remote communication, via
modems and the telephone network. AS7CD may
also be used for local communication.
AS7CK
Autostart - PC communication software (V1.07)
The AS705S only supports a local type link. The AS710S, AS720S
and AS730S support either local or remote modem links. All
applications require one interface unit (of the correct type) and
software model AS7CK installed on a PC. Local communication
also requires one of the two serial leads listed above (AS7CA or
AS7CB).
'Remote' communication requires the use of two modems and
modem leads (not available from Murphy) and a connection to
the public switched telephone network (PSTN). Note: modem
leads are normally supplied with each modem, and are NOT the
same as the serial leads used for local communication. The
modem lead at the Autostart/generator site must have a 9 way
D-connector, allowing connection to interface unit AS7CD.
FRANK W. MURPHY LTD.
Church Rd, Laverstock, Salisbury, SP1 1QZ, UK
tel: +44 1722 410055
fax: +44 1722 410088
email: sales@fwmurphy.co.uk
web: www.fwmurphy.co.uk
MURPHY SWITCH OF CALIFORNIA
41343 12th Street West,
Palmdale, CA 93551-1442, USA
tel: +1 661 272 4700
fax: +1 661 947 7570
email: sales@murphyswitch.com
web: www.murphyswitch.com
th
revision D, 19
June 2002
catalogue section 75
MACQUARRIE CORPORATION
1620 Hume Highway,
Campbellfield, Victoria 3061, Australia
tel: +61 3 9358 5555
fax: +61 3 9358 5558
email: murphy@macquarrie.com.au
mi5266
