VTS Euroheat DEFENDER 100 WHN Technical Documentation Manual

Hide thumbs Also See for DEFENDER 100 WHN:
Table of Contents

Advertisement

Quick Links

Technical documentation
EN
Check us on
DEFENDER
100-200 WHN
DEFENDER
100-200 EHN
DR-ver.1.9 (07.2014)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEFENDER 100 WHN and is the answer not in the manual?

Questions and answers

Related Manuals for VTS Euroheat DEFENDER 100 WHN

Summary of Contents for VTS Euroheat DEFENDER 100 WHN

  • Page 1 Technical documentation Check us on DEFENDER 100-200 WHN DEFENDER 100-200 EHN DR-ver.1.9 (07.2014)
  • Page 2 DEFENDER 100-200 WHN DEFENDER 100-200 EHN...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION 1.1. PRECAUTIONS, REQUIREMENTS, RECOMMENDATIONS 1.2. TRANSPORT 1.3. INITIAL STEPS TAKEN BEFORE THE INSTALLATION 2. STRUCTURE, INTENDED USE, PRINCIPLE OF OPERATION 2.1. INTENDED USE 2.2. PRINCIPLE OF OPERATION 2.3. STRUCTURE (DEFENDER 100-200 WHN, EHN) 2.4. OVERALL DIMENSIONS (DEFENDER 100-200 WHN, EHN) 3.

  • Page 4: Introduction

    For the convenience of users as well as different types of installations in commercial and industrial facilities we have designed an air curtain in two different options and three sizes: ● a DEFENDER 100 WHN curtain 1.0m wide with a water heater (8-11 kW, 1880 m ●...

  • Page 5: Assembly

    1. WATER HEATER - HEAT EXCHANGER: Maximum parameters of the heating agent for the heat exchanger are : 95°C, 1.6MPa. The aluminium and copper construction consists of copper pipes of the coil and aluminium lamellae. The connection collectors (male thread ¾``) are located in the upper part of the casing. The optimum water exchanger has been adjusted to operate in three positions: horizontal and vertical with pins going up or down.

  • Page 6: Assembly/ Disassembly Of Side Covers

    DEFENDER 100-200 WHN DEFENDER 100-200 EHN The range of the air jet - assembly height - horizontal installation - vertical installation height of assembly [m] fan speed width of the door [m] fan speed 4,0m 9,6-11 m/s* 7-9 m/s* 5-7 m/s* 2,2 m/s* 2,3 m/s* 2,3 m/s*...
  • Page 7 3.2.2. HORIZONTAL ASSEMBLY WITH USING INSTALATION HANDLES. It is possible to assemble DEFENDER 100-200 do the wall horizontally in two options: OPTION I: Assembling handles with their arms faced downwards. In this option you should first screw the installation handles to the wall (1) and then at regular intervals (for a 1m curtain it is 2 installation hanles every 700mm, for 1.5m –...

  • Page 8: Vertical Assembly With Using Instalation Handles

    DEFENDER 100-200 WHN DEFENDER 100-200 EHN 3.2.4. VERTICAL ASSEMBLY WITH USING INSTALATION HANDLES. It is possible to assemble Defender to a wall vertically on both sides of the gate (with the motor on the bottom or on the top). For this option it is not important if you screw the handles down to the unit first and then screw the whole down to the wall or first attach the handles to the wall and then screw the curtain down to the handles.
  • Page 9 NUMBER OF SERVICE VALVE WORKING POSITION Horizontal (air blown downstream) draining venting Vertical (air blown from left to right) draining venting Vertical (air blown from right to left) venting draining IMPORTANT! While venting the exchanger you should pay special attention to securing the device against accidental penetration of water into electrical elements. IMPORTANT! Follow the instruction below, when draining the heating medium: ●...

  • Page 10: Elements Of Automatics

    DEFENDER 100-200 WHN DEFENDER 100-200 EHN 4. ELEMENTS OF AUTOMATICS. Electrical connections can be carried out only by qualified electricians, according to the binding regulations of: ● industrial safety; ● sssembly instructions; ● technical documentation for each individual element of automatics. IMPORTANT! Study the original documentation delivered together with the elements of automatics, prior to the commencing of assembly and connecting of the system.

  • Page 11: Servicing

    6. SERVICING 6.1. PROCEDURE IN CASE OF DEFECTS DEFENDER 100-200 WHN/EHN Symptoms What to check Description ● Fitting of the heat exchanger terminals, using two keys acting in two opposite directions (apply the keys on each terminal), which protects against the possibility of internal breaking of the collecting pipes.

  • Page 12: Complaint Procedure

    DEFENDER 100-200 WHN DEFENDER 100-200 EHN 6.2. COMPLAINT PROCEDURE In order to report a problem with the device or elements of automation, please fill in and send the appropriate form (p.74), using one of the three available ways: 1. E-mail: vts.pl@vtsgroup.com 2.

  • Page 13: Technical Data

    – temperature of air at the inlet to the device – temperature of air at the outlet from the device – heating output of the device – water flow Δp – pressure drop in the heat exchanger Parametry DEFENDER 100 WHN [°C] 90/70 80/60 70/50 60/40 [°C]...
  • Page 14 DEFENDER 100-200 WHN DEFENDER 100-200 EHN Parametry DEFENDER 150 WHN [°C] 90/70 80/60 70/50 60/40 [°C] Flow rate of air at 3570 m /h (speed 3); air velocity at the output: 10,9 m/s; noise level 69 dB(A)* [kW] 21,3 19,6 17,8 19,5 17,8...

  • Page 15: Electric Air Curtain - Defender 100-200 Ehn

    8.2 ELECTRIC AIR CURTAIN – DEFENDER 100-200 EHN – temperature of air at the inlet to the device – temperature of air at the outlet from the device – heating output of the device Parametry DEFENDER 100 EHN [°C] Flow rate of air at 2150 m /h (speed 3);...
  • Page 16 DEFENDER 100-200 WHN DEFENDER 100-200 EHN Parametry DEFENDER 200 EHN [°C] Flow rate of air at 5000 m /h (speed 3); air velocity at the output: 10,6 m/s; noise level 71 dB(A)* [kW] 10,8/13,5** 10,8/13,5** 10,8/13,5** 10,8/13,5** [°C] 11,7/13,4** 16,7/18,4** 21,7/23,4** 26,7/28,4** Flow rate of air at 3370 m...
  • Page 17 device DEFENDER Parametras unit of measure 100 WHN 150 WHN 200 WHN 100 EHN 150 EHN 200 EHN Maximum width of a single door for one device Maximum height of door Heating output range [kW] 7,5-10 13,5-19,5 19-28 12,0 13,5 Maximum flow rate [m³/h] 1880...
  • Page 18 DEFENDER 100-200 WHN DEFENDER 100-200 EHN device DEFENDER Parameter unit of measure Prąd znamionowy silnika Weight with/without water [kg] 27,4/26,9 37,4/36,6 48,4/47,2 25,7 35,4 45,6 Engine IP * Heating output at the opening of the valve, water temperature of 90°C and temperature of inlet air 15°C. ** Heating output in the heating mode, fan in speed 3 and temperature of inlet air 5°C.

  • Page 19: Technical Information To The Regulation (Eu) No 327/2011 Implementing Directive 2009/125/Ec

    10. TECHNICAL INFORMATION TO THE REGULATION (EU) NO 327/2011 IMPLEMENTING DIRECTIVE 2009/125/EC DR 100 DR 150 DR 200 26,0% 26,0% 26,0% Total Total Total VSD-No VSD-No VSD-No 2014 2014 2014 VTS Plant Sp. z o.o., CRN 0000144190, Poland 1-2-2801-0232 1-2-2801-0233 1-2-2801-0234 0,68kW, 6182m³/h, 128Pa 0,516kW, 4239m³/h, 124Pa...
  • Page 20 DEFENDER 100-200 WHN DEFENDER 100-200 EHN IMPORTANT! The drawings with the elements of automatics contain only visualisations of sample products. IMPORTANT! One wall-mounted DX controller can support the maximum of 1 curtain of the WHN or EHN type. The maximum length of the conductor, from the curtain to the programming device, is 100 m. *The device does not contain: main switch, fuses and feeder cable Prior to the dismounting of any cover, shut down the electric power (at least by disconnecting the main switch).
  • Page 21 Complaint Form VTS POLSKA Sp. z o.o. Al. Grunwaldzka 472 A 80-309 Gdańsk Polska www.vtsgroup.com The company submitting the notification: The company that installed the equipment: Date of notification: Type of device: Factory number*: Date of purchase: Date of installation: Place of installation: Detailed description of defect: Contact person:...

This manual is also suitable for:

Defender 150 whnDefender 200 whnDefender 100 ehnDefender 150 ehnDefender 200 ehn
