1400 & 1410 Classic
1400 & 1410 Classic
One-Gallon Shaker
Models 1400, 1410-PB, 1410-00, 1410-OH, 1400-OH-E5,
1400-00-N
1400 shown on (5152-00) Pedestal Base
Optional (5153-00) Counter Base not shown
www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1400 and is the answer not in the manual?

Questions and answers

Related Manuals for RED DEVIL 1400

Summary of Contents for RED DEVIL 1400

  • Page 1 Owner’s Manual: 1400 & 1410 Classic 1400 & 1410 Classic One-Gallon Shaker Models 1400, 1410-PB, 1410-00, 1410-OH, 1400-OH-E5, 1400-00-N 1400 shown on (5152-00) Pedestal Base Optional (5153-00) Counter Base not shown www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 2: Table Of Contents

    Trouble Shooting Trouble Shooting 12 12 7. 7. Wiring Diagram Wiring Diagram 13 13 7.1 1400/1410 - PB Models 7.2 1400/1410 - 00 and -OH Models 7.3 1400/1410 - 00-N, -OH-N Models www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 3: Safety Information

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 1. Safety Information 1. Safety Information Review this owner’s manual and read all warning labels on the machine prior to use. The three main safety notifications used in this manual and on the warning labels are WARNING, CAUTION and NOTICE.

  • Page 4: Safety Precaution Labels

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 Safety Information, Continued.. 1.1 Safety Precaution labels 1.1 Safety Precaution labels AVERTISSEMENT CAUTION PRECAUCIÓN LES PARTIES EN MOUVEMENT À MOVING PARTS INSIDE PIEZAS MÓVILES ADENTRO L'INTERIEUR DE LA MACHINE...

  • Page 5: Safety Precaution Summary

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 Safety Information, Continued.. 1.2 Safety Precaution Summary 1.2 Safety Precaution Summary WARNING! Review product label, Material Saftey Data Sheet, and HMIS rating of material prior to mixing to determine potential hazards.

  • Page 6: Introduction

    (80.01 cm) separately. Shipping Weight: Understand your machine's features and • 1400-00, 1400-PB, and 1400-OH: 191 lb. (86.6 kg) proper operation to take full advantage of its • 1410-00, 1410-PB, and 1400-OH: 160 lb. (72.6 kg) capabilities. Electric Service: 120 V 60 Hz or 220 V 50 Hz (E5 only) Read this entire manual completely before operating the machine.
  • Page 7 1400-PB 120V/60 Hz 6 Min Pushbutton Timer 1400-00 120V/60Hz 15 Min Mech Timer 1400-0H 120V/50Hz 1 Hour Mech Timer 1400-00-N 120V/60Hz 15 Min Mech Timer, No Guards Mounted on Countertop or Pedestal Base. www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 8: Control Panel Pushbutton Timer

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ... Introduction, Continued 2.3 Control Panel Pushbutton 2.3 Control Panel Pushbutton 2.3 Control Panel Mechanical 2.3 Control Panel Mechanical Timer Timer Timer Timer • Timer Selection (A-D): Select the desired Turn the dial to the appropriate mix time.

  • Page 9: Assemble & Test

    Contact Red Devil Equipment Co. / Radia for replacement VHB pads. Installation, Continued.. www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 10: Valve Cap Removal

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 Assembly and Test, Continued.. 3.4 Valve Cap Removal 3.4 Valve Cap Removal Set the mixer on the upper plate of the base, 1. Remove the Valve Cap prior to operation.

  • Page 11: Operation

    3. If mixing with only one clamp on a Model • Occasionally apply a thin film of oil to the 1400, install an empty can (or a piece of 2” x 4” clamp screws. board) in the other clamp. 4. If your model has a pushbutton timer, close the clamp guard, then: a.

  • Page 12: Troubleshooting

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 6. Troubleshooting 6. Troubleshooting PROBLEM CAUSE REMEDY Connect to power source Not connected to power source Loose or broken wire Have a qualified electrician replace connection or repair the wire connection...

  • Page 13: Wiring Diagram

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 7. Wiring Diagrams 7. Wiring Diagrams 7.1 1400/1410 - PB Models 7.1 1400/1410 - PB Models 5783815 LIMIT SWITCH 5782584 GREEN PUSHBUTTTONS MOTOR KIT (90 SEC) (45 SEC) (360 SEC)

  • Page 14: 1400/1410 - 00 And -Oh Models

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Wiring Diagrams, Continued 7.1 1400/1410 - 00 and 0H Models 7.1 1400/1410 - 00 and 0H Models 15 MINUTE DIAL TIMER 5782184 5783815 1 HOUR DIAL TIMER 5758710 LIMIT SWITCH...

  • Page 15: 1400/1410 - 00-N, -Oh-N Models

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Wiring Diagrams, Continued 7.1 1400-00-N 7.1 1400-00-N 15 MINUTE DIAL TIMER 5782184 MOTOR KIT 6784902 - 110V, 60HZ 9780543 WIRE NUT 5180300 MOTOR CORD POWER CORD 5180200 - 110V, 60HZ MACHINES Wiring Diagrams, Continued..
  • Page 16 1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Wiring Diagrams, Continued 7.4 Internal Motor Wiring for 120V/60 Hz and 220V / 50 Hz 7.4 Internal Motor Wiring for 120V/60 Hz and 220V / 50 Hz Models Models...

  • Page 17: Exploded Views

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 8. Exploded Views 8. Exploded Views 8.1 Drive system 8.1 Drive system PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued..

  • Page 18: Transmission Assembly

    June 2020 ...Exploded Views, Continued 8.2 Transmission Assembly 8.2 Transmission Assembly 1400 Transmission Kit: 6785273 1410 Transmission Kit: 6785275 PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued.. www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 19: Clamp Assembly, Left

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Exploded Views, Continued 8.2 Clamp Assembly, Left 8.2 Clamp Assembly, Left *6785100 Kit, 14XX Clamp Assembly - Left Side PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued..

  • Page 20: Camp Assembly, Right

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Exploded Views, Continued 8.4 Clamp Assembly Right 8.4 Clamp Assembly Right *6785101 Kit, 14XX Clamp Assembly - Right Side PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued..

  • Page 21: Enclosure Assembly

    9785040 Enclosure, Clamp Cover - 14XX 9785592 SCREW, TYPE F 5_16-18 X 1.25 9781812 WELL NUT, #10-32 9781672 BUSHING - 1400 9785073 STRIKE PLATE, CLAMP COVER - 14XX 9781840 Nut, Keps #8-32 PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued..

  • Page 22: Clamp Cover Assembly

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Exploded Views, Continued 8.6 Clamp Cover Assembly 8.6 Clamp Cover Assembly PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued.. www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 23: Electrical Assembly Pb

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Exploded Views, Continued 8.7 Electrical Assembly PB 8.7 Electrical Assembly PB PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued.. www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 24: Electrical Assembly

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Exploded Views, Continued 8.8 Electrical Assembly OO 8.8 Electrical Assembly OO PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued.. www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 25: Electrical Assembly 0H

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Exploded Views, Continued 8.9 Electrical Assembly OH 8.9 Electrical Assembly OH PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued.. www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 26: Counter Base

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Exploded Views, Continued 8.10 Counter Base 8.10 Counter Base (5153-00) (5153-00) ID Description ID Description 9389500 Nut, Hex 3_8-16 9190300 Foot, Rubber 9161100 Washer, Flat 3_8 USS 9190800 CARRIAGE BOLT 3_8-16 X 1.50...

  • Page 27: Pedestal Base

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 ...Exploded Views, Continued 8.11 Pedestal Base 8.11 Pedestal Base (5152-00) (5152-00) PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...

  • Page 28: Ordering

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 9. Ordering 9. Ordering Replacement Parts Replacement Parts HOW TO ORDER REPLACEMENT PARTS Replacement parts can be ordered from Radia by telephone, fax, or email: RADIA 800-221-1083 763-533-2969 763-533-0015 (FAX) orders@radiaproducts.com...

  • Page 29: Warranty

    10. Warranty 10. Warranty Equipment Covered Under This Warranty Equipment Covered Under This Warranty Models 1400 and 1410-PB, 1400 and 1410-OO, 1400 and 1410-OH, 1400-OH-E5N, 1400-OO-N, and 1400-OH-N Warranty Warranty Radia warrants equipment manufactured by it and bearing its name to be free from defects in material and workmanship.

  • Page 30: Notes

    1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 11. Notes 11. Notes www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...
  • Page 31 1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 11. Notes 11. Notes www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...
  • Page 32 1785069 Rev AB Owner’s Manual:1400 & 1410 ECO 19-0002 June 2020 For sales or service, please contact For sales or service, please contact RADIA Attn: Customer Service Department 14900 21st Ave N Plymouth, Mn 55447 U.S. Telephone: 800.221.1083 International Telephone: 763.533.2969...
