QUICK START GUIDE: ZZG 646C / (MP 616 AGW)
DEAR CUSTOMER,
Carefully read the operating Keep dishwasher documentation
instructions before plugging in a safe place for possible future
dishwasher to a power outlet and use.
using the appliance. Operating
These operating instructions
instruction include tips that will
have been prepared for a range
help you avoid the risk of injury and
of appliances and some features
damage to the appliance.
described herein may not apply to
your appliance.
1

Switch on the appliance

Open the door, press the Power button to
switch on the appliance
2

Fill the detergent dispenser

To open the dispenser, turn the cap to the "open"
(left) arrow and lift it out.
Pour the rinse aid into the dispenser, be careful not
to overfill.
Replace the cap by inserting it aligned with "open"
arrow and turning it to the "closed" (right) arrow.
Check the regeneration
3
salt level
Remove the lower basket and then unscrew and
remove the cap from the salt container.
If you are filling the container for the first time,
fill 2/3 of its volume with water (around 500 ml).

Load the baskets

4
Scrape off any large amount of leftover food.
Soften remnants of burnt food in pans, then
load the baskets. Refer to the dishwasher
loading instructions.
5

Select a programme

Close the door, press the" Power" button, Press
the " Program" button to select a desired "Wash
cycle". (See the section entitled "Wash Cycle
Table"). Page 2.

Running the dishwasher

6
Close the door. A click could be heard when the
door is closed perfectly.
The machine will start working after about
10 seconds.

Switch off the appliance

7
When the working cycle has finished, the
buzzer of dishwasher will ring for 6 times,
then stop.
Turn off the appliance using the "Power"
button, shut off the water supply and open the
door of the dishwasher.
Turn off the water tap,
8
unload the baskets
Wait a few minutes before unloading the
dishwasher to avoid handling the dishes and
utensils while they are still hot and more
susceptible to breakage. They will also dry
better.
IO-DWS-1084 09.2018./1

Features and components

9
Upper Basket
Spray Arms
Lower Basket
Water Softener
Filters
Detergent Dispenser
Rinse Aid Dispenser
Cutlery basket
Fork shelf
