- Page 1 Dishwasher ZZV614W Instruction manual Sticker with serial number of appliance...
-
Page 2: Table Of Contents
CONTENTS Getting familiar with your machine ………………………………………………………. Safety information and Recommendations………………………....... Installing the machine ………………………………………………………………………. Positioning the machine ………………………………………………………………... • Water connections …………………............... • Water inlet hose ….……………………………………………………………………… • Water outlet hose …..………………............... • Electrical connection…………………………………………………………………….. • Preparing the machine for use ……………………………………………………………. - Page 3 Upper basket with racks Control Panel Upper spray arm Detergent and rinse-aid dispenser Lower basket Cutlery basket Lower spray arm Salt dispenser Filters Upper basket track latch Rating plate Active drying unit : This system provides better drying performance for your dishes.
-
Page 4: Getting Familiar With Your Machine
GETTING FAMILIAR WITH YOUR MACHINE In the stop condition while wash/dry led is On, Start/Pause led will blink. 1.) Power On/Off Button When the Power On/Off button is pressed, the lamp on the 4.) Programme selector knob Start/Pause button starts lighting. With the programme selector knob, you can select a suitable programme for your dishes. -
Page 5: Safety Information And Recommendations
When using your dishwasher, follow the precautions listed below: This appliance is intended to made by childrenwithout be used in household and supervision. For EN60335-1 similar applications such as: This appliance is not intended -staff kitchen areas in shops, for use by persons(including offices and other working children )with reduced environments;... - Page 6 This appliance must be Have a proper outlet installed earthed. In the event of a by a qualified electrician. malfunction or breakdown, Do not abuse, sit on, or stand earthing will reduce the risk on the door or dish rack of the of an electric shock by dishwasher.
- Page 7 During installation, the power Check that the detergent powder is empty after supply must not be completion of the wash cycle. excessively or dangerously bent or flattened. Do not wash plastic items unless they are marked Do not tamper with controls. The appliance is to be dishwasher safe or the equivalent.
- Page 8 Dispose of the dishwasher packaging material correctly. All packaging materials can be recycled. Plastic parts are marked with the standard international abbreviations: for polyethylene, e.g. sheet wrapping material for polystyrene, e.g. padding material POM polyoxymethylene, e.g. plastic clips polypropylene, e.g. Salt filler Acrylonitrile Butadiene Styrene, e.g.
-
Page 9: Technical Specifications
Technical specifications Capacity 12 place settings Height 820 mm - 870mm Width 598 mm Depth 573 mm Net Weight 41 kg Electricity input 220-240 V, 50 Hz Total Power 1900 W Heating Power 1800 W Pump Power 85 W Drain Pump Power 57,5 W Water supply pressure 0.03 MPa -1 MPa... -
Page 10: Installing The Machine
INSTALLING THE MACHINE Positioning the machine When determining the place to put your machine on, take care to choose a place where you can easily load and unload your dishes. Do not put your machine in any location where there is the probability for the room temperature to fall below 0°... -
Page 11: Electrical Connection
Water outlet hose The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink. -
Page 12: Preparing The Machine For Use
Prior to using the machine for the first time Check whether the electricity and supply water specifications match the values indicated by the • installation instructions for the machine. Remove all packaging materials inside the machine. • Set the water softener. •... -
Page 13: Testing Strip
In order to understand whether or not the amount of softener salt in your machine is sufficient, check the transparent section on the salt compartment cap. There is sufficient salt if the transparent section is green. Salt has to be added if the transparent section is not green. Testing strip The washing effectiveness of your machine depends on the softness of the tap water. - Page 14 Adjusting salt consumption Adjust the water softener according to how hard your tap water is. Move the programme selector knob to the 0 (Reset) position while your machine is not in operation. After resetting your machine, press the Start/Pause button and keep it pressed down.
-
Page 15: Detergent Usage
Detergent usage Use a detergent specifically designed for use in domestic dishwashers. You can find powder,gel,and tablet detergents in the market that have been designed for household dishwashers. Detergent should be put into the compartment prior to starting the machine. Keep your detergents in cool, dry places out of reach of your children. -
Page 16: Filling With Rinse Aid And Making The Setting
They produce good results for certain types of usage only. If you are using this type of • detergents, you need to contact the manufacturers and find out about the suitable conditions of use. When the conditions of use of such products and the machine settings are appropriate, •... -
Page 17: Loading Your Dishwasher
Warning: Use only those rinse aid materials which are allowed for use in the machine. As rinse aid residues left as a result of overflowing will create extremely high amounts of foam and thus reduce the washing performance, remove the excess amount of rinse aid by wiping it with a rag. LOADING YOUR DISHWASHER If you properly place your dishes into the machine, you will be using it in the best way in terms of energy consumption, washing and drying performance. - Page 18 Top basket height adjustment while it is full Machine is designed to let you adjust the height of your top basket upwards or downwards, without removing it from your machine when it is full, and create large spaces at the top or bottom area of your machine as needed.
-
Page 19: Alternative Basket Loads
Alternative basket loads Lower Basket Top basket Faulty loads Important Note for Test Laboratories For detailed information on performance tests, please contact following address: “dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door. -
Page 20: Programme Descriptions
PROGRAMME DESCRIPTIONS Programme items Programme No Reference Programme Super 50 m n . ** Qu ck 30 m n. Intens ve names and temperatures 40° C 50° C 65° C 65° C Type of food co ee, m lk, tea, co ee, m lk, tea, soups, sauces, soups, sauces,... -
Page 21: Switching On The Machine And Selecting A Programme
SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Switching on the machine Press the Power On/Off key. Select the program suiting your dishes via the Program Selection button. Once the Power On/Off key Start the program pressing is pressed, the lamp Power the Power Start/Pause key. -
Page 22: Changing A Programme With Resetting
Changing a programme with resetting If you would like to cancel a program while a washing program is resumed Press once the Power Turn the Program Start/Pause key. Selection Button to Reset The program will have been cancelled once the drying lamp goes off and the lampFinshed is The machine will discharge the Press once the Power... -
Page 23: Maintenance And Cleaning
MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine. -
Page 24: Spray Arms
Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left. -
Page 25: Failure Codes And What To Do In Case Of Failure
FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE ERROR CODE ERROR CONTROL DESCRIPTION Wash / Dry Start/Pause • Make sure the water input tap is totally open and that Inadequate water there is no water cut. supply • Close the water input tap, separate the water input hose from the tap and clean the filter at the connection end of the hose. - Page 26 If water is left inside the machine at the end of the programme The water drain hose is clogged or twisted. • The filters are clogged. • The programme is not finished yet. • If the machine stops during a wash operation Power failure.
-
Page 27: Practical And Useful Information
PRACTICAL AND USEFUL INFORMATION Whenever you will not be operating your machine Unplug the machine and then turn the water off. • Leave the door slightly ajar in order to prevent the formation of unpleasant smells. • Keep the machine interior clean. •... - Page 28 Sheet of household dishwasher according to EU Directive 1059/2010: Manufacturer Amica Wronki S.A. Type ZZV614W Standard place settings Energy efficiency class Annual energy consumption - kWh (AEC) ( 280 cycles) Energy consumption of the standard cleaning cycle 0,95 Power consumption of off-mode (W)
