- Page 1 Ins-30039 2A/12V DC boxed power supply with Net2 ACU INPUT AC 100-240V 50 / 60 Hz 1.2A OUTPUT DC 13.8V...
- Page 2 Monday - Friday from 07:00 - 19:00 (GMT) Saturday from 09:00 - 13:00 (GMT) Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/ Fitting 1. Screws and wall plugs are provided in a fitting kit. With reference to the diagrams, determine where the top, central mounting position is required and drill a hole suitable for a No 8 wall plug.
- Page 3 Layout 12V DC Outputs Paxton Net2 control unit INPUT AC 100-240V 50 / 60 Hz 1.2A OUTPUT DC 13.8V Tamper Switch Ratings Label Back-up battery The Tamper switch type and position will vary due to the different case styles.
- Page 4 Dimensions Metal Cabinet 25 mm 116 mm 320 mm 268 mm 68 mm 68 mm 136 mm 232 mm...
- Page 5 Plastic Cabinet 18 mm 118 mm 320 mm 284 mm 98 mm 98 mm 196 mm 236 mm...
- Page 6 Unpack the unit with care and inspect for transit damage. If damage is suspected, the unit must not be used or tested, but should be returned to Paxton for investigation and the damage reported to the carrier.
- Page 7 The Electro-Magnetic Compatibility (EMC) Directive - 89/336/EEC The Restriction of Hazardous Substances (RoHS) Directive - 2002/95/EC A Net2 nano ACU or a Hands free interface cannot be installed in the Metal cabinet as this would block the RF signal used for...
- Page 8 1.2A Mains supply frequency 50Hz 60Hz +/- 3Hz ACU Electrical See accompanying documentation ( ins-30000 - Net2 classic, ins-30075 - Net2 nano, ins-30080 - Net2 plus ) Environment 0 °C + 45 °C Operating temperature - Battery limits Waterproof Dimensions...
