Eaton Powerware SPD3Gi/A Installation Instructions

SPD3Gi/A S
URGE
(3 Phase, 380-520V, 40kA per mode)
INSTALLATION INSTRUCTIONS
FEATURES
•
Extended voltage range
•
Common-earth protection (L-E, N-E)
•
Compact solution for 3-phase protection
•
DIN43880 case, 35 mm DIN-rail mountable
•
All MOVs thermally protected
•
Includes dry-contact alarm
Applications
•
Secondary power circuits / Sub-boards
•
Telecommunication Systems / Rectifiers
•
Process and Control Systems / Homes & Units
•
Computer Systems / Medical Systems
•
All sensitive Electronic Equipment
SPECIFICATIONS
Manufacturers name and model
Method of mounting
Input voltage
Maximum continuous operating
voltage - MCOV
Temporary over-voltage – TOV
Service type
Test classification
Supply current
Initial clamp voltage
Maximum rated surge current -
Ismax 8/20us
Nominal surge current - In
8/20us
Residual voltage (Vpl) @
3kA, 8/20uS
Residual voltage (Vpl) @ Ismax
40kA, 8/20uS
Energy absorbtion (2ms)
Nominal surge lifetime (In)
Internal protection (fusing)
External disconnector
requirements
Terminations
Alarms/indicators
Location Category
Enclosure rating
Applicable standards.
Dimensions
Weight
Environment
Warranty
Specification are subject to change without notice. Copyright 2005 Eaton Power Quality Pty Ltd
D
IVERTER
Eaton Powerware
SPD3Gi/A
Fixed. DIN Rail mount
220-300VAC (380-520V)
40-70Hz
350VAC
420VAC, 15 mins
TN-S and TT (3-wire with
grounded neutral)
Class II
50mA
680V
40kA
20kA
≤1.2kV L-E
≤1.4KV N-E
≤2.1Kv L-E
≤2.45KV N-E
3640j
20kA (8/20uS), 20 times
MOV thermal fuses 135°C
Gg/Gl HRC fuses, 1 per
phase, 125A maximum.
2
Power terminals 16mm ,
2
Alarm terminals 1.5mm
5 indicators, dry contact
alarm relay –
250VAC/32VDC, 5A
Indoor
IP20
IEC61643-1, IEC610006,
ANSI/IEEE C62.41,
AS1768-2003, AS3100
DIN43880, 4 units (70mm)
200g
-10 to 60C, 0-90%RH
12 months, workmanship
and materials
Technical Specification – SPD3Gi/A
Web: http://www.powerware.com.au
FUNCTIONAL DESCRIPTION
The SPD3i is designed to protect 3-phase power
systems against damage from surges and spikes
caused by lightning and other electrical sources. The
unit is intended for point-of-entry or sub-board
protection and is connected in parallel with the power
system via HRC fuses. This unit is available in
various models
applications. Check that the model you have
purchased is rated correctly for your power system.
.
This model (SPD3Gi/A) is designed for TN-S and
TT power systems in the range of 220-300V(380-
520V). If your power system is TN-C, TNC-S or IT,
or of a different voltage, this model is NOT
suitable.
Please contact your supplier for a suitable model to
suit your application.
OPERATION
Two lamps on the front panel indicate the operation
status of the unit. The 'OK' lamp indicates that power
is applied to the unit and the 'FAULT' lamp indicates
reduced protection. If the 'FAULT' lamp is lit it is likely
that the unit is damaged and must be replaced. If the
breaker/fuse is intact and power is definitely being
supplied through the unit (check with meter) but the
'OK' lamp doesn't light then the unit is faulty and
must be replaced.
WARRANTY
Eaton Power Quality warrants this unit against faulty
parts and workmanship for a period of 12 months
from the date of purchase. If this product fails to
operate correctly, please contact your Eaton
representative. This warranty doesn't cover neglect
or intentional misuse. As this product is intended for
use in electrically harsh environments no claim is
made of suitability for purpose. This unit is designed
to reduce the likelihood of damage, not prevent it.
Please also note that an excessive surge, such as
from a direct lightning strike to the site or a power
system fault, may cause damage to the unit and
render it inoperable. A unit that has been damaged in
this way is not warrantable.
Page 1 of 2
Phone: 1300 UPS UPS
for different
For installation details,
see over page.
voltages and
Tvss Doc# 510075
